CARLO GAVAZZI GDP503L120V Industrial Contactor
The GDP503L contactor is a three-pole industrial switch rated for 40A with a coil voltage of 120V. Designed for HVAC, pumps, and compressor applications, it features UL recognition for North America, screw or lug terminals, high power switching up to 600VAC, and fast-on coil connections. It offers reliable performance with a contact life of 500,000 cycles, suitable for demanding electrical loads. Its environmental ratings include operation from -5°C to +40°C, with optional de-rating factors at higher temperatures, and conforms to RoHS standards for eco-friendliness.
CARLO GAVAZZI GDP503L120V Industrial Contactor Specifications:
- Amperage Rating: 40 Amps
- Number of Poles: 3
- Control Voltage: 120 VAC
- Line Voltage: up to 600VAC
- Switching Capacity: resistive up to 100A, inductive up to 90A
- Terminals: Screw or lug terminals available
- Coil Power: 83 VA in-rush, 14 VA sealed
- Electrical Life: 30,000 cycles
- Mechanical Life: 500,000 cycles
- Operating Temperature: -5°C to +40°C, with de-rating factors beyond 50°C
- Environmental: RoHS compliant
- Protection: UL recognized for US and Canada
- Frequency: 50/60 Hz
- Dimensions: Compatible with standard DIN rail and panel mounting
Buy the Buy CARLO GAVAZZI GDP503L Part Number GDP503L120V Online
Order the CARLO GAVAZZI GDP503L contactor online today to ensure dependable switching for your HVAC, motor control, or industrial automation needs. Designed with UL recognition and tested for up to 500,000 cycles, this 3-pole contactor features 40A capacity, a 120V control voltage, and high power switching capabilities up to 600VAC. Available with screw or lug terminals for flexible wiring options, it provides safe and efficient operation in demanding electrical environments. Invest in quality, reliability, and fast online procurement to keep your systems running smoothly.
Get CARLO GAVAZZI GDP503L today—built for industrial automation, HVAC, and reliable motor control with long-lasting durability.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI GDP503L120V?
You can click on the BUY or RFQ button to purchase GDP503L120V from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part GDP503L120V?
You can download the GDP503L120V datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of GDP503L120V?
CARLO GAVAZZI
