CARLO GAVAZZI RCI002A240V Industrial Relay
The RCI series industrial relay is a versatile monostable switch suitable for various automation and control applications. Featuring 2 or 3 changeover contacts, it supports coil voltages from 5V to 240V AC/DC, and delivers a high electrical life of 100,000 cycles with a mechanical life of 10 million cycles. Mounted on DIN sockets, it includes features such as indicator LEDs, push arms, and test flags. Certified with UL, CSA, CE, and RoHS, this relay offers reliable switching performance at a maximum of 10A switching current and various contact configurations.
CARLO GAVAZZI RCI002A240V Industrial Relay Specifications:
- Coil Voltage Range: 5VDC to 240VAC
- Contact Rating: 10A 250VAC/30VDC
- Contact Arrangement: DPDT, 3PDT, AgSn02 material
- Electrical Life: 100,000 cycles
- Mechanical Life: 10,000,000 cycles
- Coil Resistance: 1650 ohms at 110/120V AC, 6800 ohms at 220/240V AC
- Insulation Resistance: > 2000V dielectric strength
- Dimensions: 8-PIN or 11-PIN DIN socket options, load capacity 10A at 250VAC
- Operational Temp Range: -40°C to +85°C
- Approval Certifications: UL, CSA, CE, RoHS
- Operational Humidity: 35% to 85%
Buy the Carlo Gavazzi Series RCI Industrial Relay: RCI002A240V
Purchase the Carlo Gavazzi RCI002A240V industrial relay online today and enhance your control system with this high-performance, certified switch. Designed for durability with a long electrical and mechanical life, it features versatile contact configurations and supports a wide range of coil voltages from 5V to 240V AC/DC. Ideal for automation applications, its robust DIN socket mounting and approvals from UL, CSA, CE, and RoHS ensure safety and compliance. Order now to benefit from fast delivery and reliable operation in demanding environments.
Buy Carlo Gavazzi RCI002A240V industrial relay now and experience unmatched reliability and performance for your automation needs.
