CARLO GAVAZZI RAM1B23D125 Industrial Solid State Relay
The product is a 1-phase solid state relay designed for industrial applications, featuring zero switching or instant-on switching with LED indication, and a IP20 protection cover. It supports direct copper bonding technology, has multiple input voltage ranges, and operational ratings up to 125 AACrms and 690 VACrms. Suitable for resistive, inductive, and capacitive loads, it includes overvoltage protection, built-in snubber, and touch protection. Certified with CE and UKCA markings, it’s ideal for reliable load control in industrial automation systems.
CARLO GAVAZZI RAM1B23D125 Industrial Solid State Relay Specifications:
- Housing material: Noryl, black
- Mounting screws: M5
- Housing weight: 60g (25A, 50A), 100g (75A, 100A, 125A)
- Electrical ratings: Up to 125 AACrms, 690 VACrms
- Blocking voltage: Up to 1600 Vp
- Input control voltage ranges: 3-32 VDC and 20-280 VAC/22-48 VDC
- Opto-isolation: > 4000 VACrms
- Overvoltage protection: Yes (self-switching, suffix Z option)
- Output ratings: Resistive, inductive, capacitive loads
- Protection: IP20 touch protection cover
- Approvals: CE-marked, UKCA marked
- Terminal type: Faston tabs, copper, nickel-plated
- Control terminals: M65 screw, 4.8mm width; M8 screw, 6.3mm width
- Temperature range: -40°C to +80°C (operating), -40°C to +100°C (storage)
- Peak surge current: Up to 200A (at specific ratings)
Buy the Carlo Gavazzi RAM1B – Reliable Solid State Relay for Industrial Applications
Purchase the Carlo Gavazzi RAM1B23D125 series relay online today. Designed for industrial automation, it features zero or instant switching with LED indicators, supporting loads up to 125A and 690VAC. Its robust IP20 housing, overvoltage protection, isolated input and output, and certified safety standards ensure reliable operation across resistive, inductive, and capacitive loads. Perfect for controlling motors, heaters, and other industrial equipment, this relay delivers high performance and safety when ordered online.
Order your Carlo Gavazzi RAM1B23D125 Series high-performance industrial relay today and ensure dependable control for resistive, inductive, and capacitive loads in your automation projects.
