CARLO GAVAZZI RAM1A60D50 Industrial Solid State Relay
The RAM1A60D50 is a high-performance, industrial 1-phase solid state relay designed for resistive, inductive, and capacitive loads. Featuring zero switching with direct copper bonding technology, it offers reliable operation with LED indication, IP20 protection cover, and integrated overvoltage protection. The relay supports input voltages of 20-280 VAC or 22-48 VDC, rated operational currents of up to 50A, and blocking voltages up to 1600 Vp. Its robust construction ensures durability in demanding industrial applications, making it ideal for phase control and automation systems.
CARLO GAVAZZI RAM1A60D50 Industrial Solid State Relay Specifications:
- Housing Material: Noryl, black
- Mounting: M5 screws, torque 1.5-2.0Nm
- Input Voltage Range: 20-280 VAC / 22-48 VDC
- Control Voltage: 20-280 VAC or 22-48 VDC
- Rated Operational Current: 50A
- Rated Operational Voltage: Up to 125A AC, 690V AC
- Blocking Voltage: Up to 1600 Vp
- Output Type: Anti-parallel thyristor
- Protection Class: IP20 enclosure with touch protection cover
- Connections: M65 screw terminal, wire range 14-10 AWG, 0.5-2.5 mm²
- Certifications: UL, cUR, CSA, VDE, CE, UKCA
- Isolation: Input to output 4000 Vrms, Input/output to case 4000 Vrms
- Response Time: < 12 ms for pick-up, < 40 ms for drop-out
- Operating Temperature Range: -40°C to +80°C
- Maximum Junction Temperature: 125°C
- Dimensions: Refer to datasheet for dimensions and heatsink compatibility
Buy the Carlo Gavazzi Series Industrial Solid State Relay: RAM1A60D50
Enhance your industrial automation with the Carlo Gavazzi Series RAM1A60D50, a reliable 1-phase solid state relay with LED indicators, IP20 protection, and support for control voltages up to 280 VAC/DC. Designed for resistive, inductive, and capacitive loads, it offers rated currents up to 50A and blocking voltages up to 1600 Vp. Its robust construction ensures durability and performance in demanding industrial environments. Order online today for efficient, safe, and dependable load control in your automation system.
Order your Carlo Gavazzi Series RAM1A60D50 today and give your industrial automation projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RAM1A60D50?
You can click on the BUY or RFQ button to purchase RAM1A60D50 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RAM1A60D50?
You can download the RAM1A60D50 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RAM1A60D50?
CARLO GAVAZZI
