CARLO GAVAZZI RGTS24120GV00 Voltage Soft Starter
The RGTS series is a compact, fully solid-state soft starter designed for single-phase two-wire AC induction motors used in applications like pumps, fans, compressors, and conveyors. It offers adjustable motor ramp-up time and initial torque via built-in potentiometers. The unit features LED indicators for control voltage and full-voltage status, ensuring easy operation. It complies with UL508A, has a 100 kArms short circuit current rating, and supports a wide input voltage range of 24 VAC/DC or 100-240 VAC, making it suitable for installations with weak power supplies.
CARLO GAVAZZI RGTS24120GV00 Voltage Soft Starter Specifications:
- Material: PA66, RAL7035
- Assembly: DIN rail
- Touch protection: IP20
- Weight: approx. 660 g
- Overvoltage category: III
- Supply voltage: 24VDC, -15%/+20%, or 90-265VAC, -15%/+15%
- Max. supply current: 80mA (24VDC), 60mA (AC)
- Isolation: Input to Output 2.5 kVrms, Output to Case 4 kVrms
- Power connections: M4 screw with captivated washer (12A, 16A models) or M5 screw with Box Clamp (25A model)
- Stripping length: 11-12mm
- Operating temperature: -40°C to +60°C
- Relative humidity: <95% non-condensing at 40°C
- Vibration resistance: 2g/axis
- Impact resistance: 15/11 g-ms
- Protection: IP20, Pollution degree 2, Installation category III
- Control voltage (A1-A2): Series wiring with motor starter; no separate control input required
- Rated operational current at 40°C: 12A, 16A, 25A respectively
- Motor ratings: 0.55kW/0.5 HP (12A), 0.55kW/0.5 HP (16A), 1.5kW/1 HP (25A) at 110-120VAC; 1.1kW/2 HP, 1.5kW/2 HP, 3kW/3 HP at 220-240VAC
- Adjustable ramp-up time: 0.5-5 seconds
- Initial torque adjustment: 10%-80%
- Protection: UL short circuit rated up to 100,000A rms, various fuse sizes recommended for protection
- Standards: EN/IEC 60947-4-2, UL508, IEC61000-4 series EMC immunity and emission standards
Buy the Gavazzi Series RGTS Voltage Soft Starter: RGTS24120GV00
Order the Gavazzi RGTS24120GV00 online today to enhance your motor control system with a compact, fully solid-state soft starter. Its adjustable ramp-up and initial torque provide optimal motor startup performance. Certified for UL508A, this device supports a wide voltage range of 24VDC or 100-240VAC, ensuring reliable operation even with weak power supplies. Simple wiring, LED indicators, and DIN rail mounting make installation easy. Perfect for pumps, fans, compressors, and conveyors, ensuring smooth startup with minimal mechanical stress.
Buy Gavazzi RGTS24120GV00 now and experience unmatched reliability and performance in single-phase motor control with adjustable ramp-up and torque.
