CARLO GAVAZZI RM1D200D20 DC Solid State Relay
The RM1D series comprises DC solid state relays designed for high-current switching applications up to 100A and supply voltages up to 600VDC. Features include a low power dissipation MOSFET output, control voltages from 4 to 32 VDC, an LED indicator for control presence, and clip-on IP20 protection covers. These relays are ideal for controlling heaters, solenoid valves, and test equipment, offering quick response times, high reliability over many switching cycles, and built-in electrical isolation of 3750 Vrms. Suitable for panel mounting or heatsink assembly, the RM1D series ensures efficient, trouble-free operation in demanding environments.
CARLO GAVAZZI RM1D200D20 DC Solid State Relay Specifications:
- Housing material: Noryl, black
- Mounting: Panel mount
- Touch Protection: IP20
- Input to case dielectric withstand: 3750 Vrms
- Output maximum current: 10 ADC up to 60 VDC, 20 ADC up to 200 VDC, 50 ADC up to 500 VDC, 100 ADC up to 60 VDC
- Maximum output voltage: 60 VDC, 200 VDC, 500 VDC respectively
- Control voltage range: 4-32 VDC
- Response time: Pickup 100 ps, Drop-out 100 μs to 150 μs depending on model
- Leakage current: 0.1 mA at rated voltage
- Operating temperature: -20°C to 80°C
- Thermal protection: Internal transil, optional heatsink required for high current models
- Isolation voltage: 3750 Vrms
Buy the Carlo Gavazzi Series RM Series DC Solid State Relay: RM1D200D20
Order the Carlo Gavazzi RM1D series DC solid state relay online now to leverage its high current capacity, rapid switching response, and robust isolation features. Designed for industrial automation, these relays provide reliable power switching up to 100A and up to 600VDC, ensuring precise control of heaters, solenoid valves, and test equipment. With a control voltage range from 4 to 32 VDC, LED control indicator, and versatile mounting options with heatsink compatibility, this product blends performance, durability, and easy integration for demanding electrical systems.
Get Carlo Gavazzi RM1D200D20 today—built for precision and long-lasting durability in high-current DC switching.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RM1D200D20?
You can click on the BUY or RFQ button to purchase RM1D200D20 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RM1D200D20?
You can download the RM1D200D20 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RM1D200D20?
CARLO GAVAZZI
