CARLO GAVAZZI SPMA12301 Modular Power Supply
The SPMA modular switching power supplies are designed for industrial and building automation, providing up to 100W power. They feature high efficiency (up to 89%), wide input ranges (85-264 VAC, 120-350 VDC), and compact, slim designs suitable for DIN rail mounting. They meet CE, UL, and other safety standards, with excellent isolation (4 kVAC) and protections against overcurrent, overvoltage, and short circuits. Options include conformal coating for harsh environments, making them ideal for automotive battery chargers, hazardous locations, and automation systems. Operating from -30°C to +70°C, they ensure reliable performance in demanding conditions.
CARLO GAVAZZI SPMA12301 Modular Power Supply Specifications:
- Output Power: up to 100W
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Input Voltage Range: 85 VAC to 264 VAC, 120 VDC to 350 VDC
- Efficiency: Up to 89%
- Isolation Voltage: 4 kVAC (Primary - Secondary)
- Operating Temperature: -30°C to +70°C
- Storage Temperature: -40°C to +85°C
- Humidty: 10% to 95% RH non-condensing
- Protection: Over Current, Over Voltage, Short Circuit
- Vibration Resistance: 10-500Hz, 2G
- Shock Resistance: 15G for 11ms
- Mounting: DIN rail
- Ingress Protection: IP20
- Case Material: Plastic
- MTBF: >300,000 hours
- Certifications: UL508, UL62368, UL1310 Class 2, UL 121201 Class 1 Div 2
- Dimensions: Varies per model, from 15W in 17.5mm to 100W in 70mm width
Buy the Carlo Gavazzi SPMA12301 – Reliable Power Supply for Industrial Applications
Order the Carlo Gavazzi SPMA12301 power supply online today and benefit from high efficiency, wide input voltage range, and robust safety features. Designed for industrial and automotive applications, this power supply delivers up to 100W power with excellent protection against overloads, short circuits, and surges. Its compact design ensures easy installation in tight spaces, while certifications like UL and CE guarantee safety and quality. Enhance your automation and control systems by choosing this reliable component for demanding environments and long-term operation.
Buy Carlo Gavazzi SPMA12301 now and experience unmatched reliability and performance in automation and industrial environments.
