CARLO GAVAZZI SPMA12601 Modular Power Supply
The SPMA series modular switching power supplies are designed for industrial and building automation, delivering up to 100W of power in a compact form. They feature high efficiency up to 89%, universal AC/DC input, and multiple output options including 5VDC, 12VDC, 15VDC, and 24VDC. These supplies meet CE, UL, and UL 62368 standards, with a 4kVAC isolation voltage suitable for hazardous locations. They operate reliably from -30°C to +70°C, with optional conformal coating for harsh environments, providing safe, robust power solutions for automation applications.
CARLO GAVAZZI SPMA12601 Modular Power Supply Specifications:
- Input Voltage Range: 85 VAC to 264 VAC, 120 VDC to 350 VDC
- Output Voltage Options: 5VDC, 12VDC, 15VDC, 24VDC
- Rated Power: Up to 100W
- Efficiency: Up to 89%
- Isolation Voltage: 4kVAC between primary and secondary
- Operating Temperature: -30°C to +70°C
- Storage Temperature: -40°C to +85°C
- Vibration Resistance: 10-500 Hz, 2G for 60 min along X, Y, Z axes
- Shock Resistance: 15 G, 11 ms, along X, Y, Z axes
- Certifications: UL508, UL62368, UL1310 Class 2, UL 121201 Class 1 Div 2
- Protection: Over Current, Over Voltage, Short Circuit
- Dimensions: 15W in 17.5mm (1 DIN), 100W in 70mm (4 DIN)
- Ingress Protection: IP20
- Conformal Coating: Optional for harsh environments
- Temperature Derating: Refer to derating diagram
- Humidiity: 10-95% RH non-condensing
Buy the Carlo Gavazzi Series SPMA Power Supply: SPMA12601
Order the Carlo Gavazzi SPMA12601 power supply online today to ensure your automation systems operate reliably with high efficiency. This versatile device provides multiple output options, is compliant with global safety standards, and is built to operate across a wide temperature range. Its compact design saves space and is suitable for hazardous locations when installed in an enclosure. With optional conformal coating, it withstands harsh environments, offering long-lasting, safe power solutions for industrial and building automation projects.
Buy Carlo Gavazzi SPMA12601 now and experience unmatched reliability and high-performance power supply for demanding industrial applications.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI SPMA12601?
You can click on the BUY or RFQ button to purchase SPMA12601 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part SPMA12601?
You can download the SPMA12601 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of SPMA12601?
CARLO GAVAZZI
