CHOMERICS 771231138707 EMI Shielding Gasket
The Soft-Shield 3500 is an economical EMI shielding gasket fabricated from conductive nickel-plated copper polyester taffeta fabric wrapped around open cell urethane foam. It provides low-closure force, typically under 1 lb/in, with excellent shielding effectiveness over 100 dB from 50 MHz to 10 GHz. The gasket is RoHS, REACH, and UL 94 V-0 compliant, offering good low compression set properties, abrasion resistance, and customizable profiles for electronic enclosures, server faceplates, and grounding applications. Designed for reliable EMI/EMC performance, it is available in various profiles, lengths, and optional adhesion features.
CHOMERICS 771231138707 EMI Shielding Gasket Specifications:
- Shielding Effectiveness: >100dB from 50 MHz to 10 GHz
- Material: Conductive nickel-plated copper polyester fabric wrapped on open cell urethane foam
- Closure Force: Typically less than 1 lb/in (0.175 / mm)
- Compression Set: Less than 15%
- Temperature Range: -40°C to +70°C
- Compliance: RoHS, REACH, UL 94 V-0
- Typical Properties: Flammability UL 94V-0, Peel Strength: over 90 lb/in (0.7 N/mm), ASTM C168, ASTM D3574
- Physical Dimensions: Custom profiles available, lengths cut to customer specifications, minimum wall width 0.060 inch (1.52 mm)
Buy the Buy Parker Chomerics Soft-Shield 3500 Part Number 771231138707 Online
Discover the Parker Chomerics Soft-Shield 3500, an affordable, effective EMI shielding gasket with nickel-plated copper fabric over foam. It features excellent shielding effectiveness (>100 dB from 50 MHz to 10 GHz), low closure force, and excellent durability, making it ideal for electronic enclosures, server faceplates, and grounding applications. Customizable in profiles and lengths, it is RoHS, REACH, and UL 94 V-0 compliant, ensuring safety and environmental standards. Enhance your electromagnetic compatibility with this versatile and reliable gasket by ordering online today for quick delivery and optimal performance.
Order your Parker Chomerics Soft-Shield 3500 gasket today and ensure reliable EMI/EMC protection for your electronic enclosures and ground connections.
