CHOMERICS 77123175G8709 EMI Shielding Gasket
Soft-Shield 3500 is an economical EMI shielding gasket featuring plated-fabric wrapped foam with low closure force and high shielding effectiveness from 50 MHz to 10 GHz. Made with nickel-plated copper fabric over foam, it provides reliable grounding and eliminates EMI/EMC gaps, ideal for electronic enclosures, server faceplates, consumer electronics, and grounding applications. Available in various profiles, including rectangle, D-shape, and stealth, it offers excellent low compression set properties, abrasion resistance, and compliance with RoHS, REACH, and UL 94 V-0 standards. It ensures durable performance in low-force, high EMI protection scenarios.
CHOMERICS 77123175G8709 EMI Shielding Gasket Specifications:
- Shielding Effectiveness: >100dB from 50 MHz to 10 GHz
- Closure Force: less than 1 lb/in (0.175 N/mm)
- Compression Set: less than 15%
- Operating Temperature: -40°F to 158°F (-40°C to 70°C)
- Material: Nickel-plated copper polyester fabric over open cell urethane foam
- Profiles Available: Over 250 custom profiles including rectangle, D-shape, and stealth
- Flammability: UL 94 V-0
- Compliance: RoHS, REACH, UL
- Adhesive: Optionally with pressure-sensitive adhesive and extended liner
- Dimensions: Cut to length, various profile sizes, typical wall thickness varies from 0.015 to 0.75 inches
- Application: EMI/RFI shielding, electronic enclosures, server faceplates, grounding, vent seals
Buy the Parker Series Soft-Shield 3500 EMI Shielding Gasket: 77123175G8709
Purchase Parker Soft-Shield 3500 EMI shielding gasket online today and ensure effective electromagnetic interference protection for your electronic enclosures. Our gasket features plated copper fabric over foam, providing high shielding effectiveness over 100dB from 50 MHz to 10 GHz. With low closure force less than 1 lb/in, it guarantees reliable grounding and durability in low-force applications. Available in multiple profiles, including rectangle, D-shape, and stealth, it offers excellent compression set, abrasion resistance, and compliance with UL and RoHS standards. Easy to order in cut-to-length options.
Buy Parker Soft-Shield 3500 EMI shielding gasket now and experience unmatched reliability and performance for your electronic enclosures and grounding needs.
Frequently Asked Questions
Where can I buy CHOMERICS 77123175G8709?
You can click on the BUY or RFQ button to purchase 77123175G8709 from an authorized CHOMERICS distributor.
How do I troubleshoot issues or seek technical support for part 77123175G8709?
You can download the 77123175G8709 datasheet or visit the CHOMERICS website for support.
Who is the manufacturer of 77123175G8709?
CHOMERICS
