CHOMERICS 77123150G8711 EMI Shielding Gasket
Soft-Shield 3500 is an economical EMI shielding gasket featuring plated-fabric wrapped foam that offers low-closure force, high shielding effectiveness from 50 MHz to 10 GHz, and excellent low compression set. Designed with conductive nickel-plated copper fabrics, it ensures reliable grounding and EMI/EMC gap elimination. Suitable for electronic enclosures, server faceplates, consumer electronics, and grounding applications, this versatile gasket with over 250 profiles available provides effective, low-cost shielding with compliance to RoHS, REACH, and UL 94 V-0 standards, ensuring durability and electrical performance.
CHOMERICS 77123150G8711 EMI Shielding Gasket Specifications:
- Shielding Effectiveness: over 100 dB from 50 MHz to 10 GHz
- Closure Force: less than 1 lb/in (0.175 N/mm)
- Compression Set: less than 15%
- Material: Nickel-plated copper polyester taffeta fabric wrapped around open cell urethane foam
- RoHS, REACH, and UL 94 V-0 compliant
- Operating Temperature: -40°F to +158°F (-40°C to +70°C)
- Physical Dimensions: Typically cut to specified lengths and profiles, width varies depending on profile
- Profiles: Over 250 available, including rectangle, D-shape, stealth, and knife-edge profiles
- Resistance: Low contact resistance, abrasion and shear resistant conductive jackets
Buy the Chomerics 77123150 U–Reliable EMI Shielding Gasket for Industrial Applications
Enhance your electronic device protection with Chomerics EMI shielding gasket. Designed for durability, high shielding effectiveness, and low closure force, this versatile gasket fits various profiles and applications including server faceplates, consumer electronics, and grounding solutions. With over 250 profiles and compliant with industry standards, it guarantees reliable EMI/EMC performance. Easily cut to length, available with or without pressure-sensitive adhesive, and tested for low compression set, this gasket ensures excellent electrical grounding and shielding for your critical electronic components and enclosures.
Get Chomerics 77123150 today—built for low closure force, high shielding effectiveness, and long-lasting durability in electronic enclosures.
Frequently Asked Questions
Where can I buy CHOMERICS 77123150G8711?
You can click on the BUY or RFQ button to purchase 77123150G8711 from an authorized CHOMERICS distributor.
How do I troubleshoot issues or seek technical support for part 77123150G8711?
You can download the 77123150G8711 datasheet or visit the CHOMERICS website for support.
Who is the manufacturer of 77123150G8711?
CHOMERICS
