Carling Technologies VRT Contura Sealed Rocker Switch
CARLING TECHNOLOGIES V-Series Contura II & III switches are versatile rocker switches designed for a wide range of applications. They offer extensive customization options for ratings, circuits, colors, and illumination, making them suitable for diverse industrial needs. The switches are sealed to IP66/68 standards, providing protection against dust, water, and pressure, and are recognized to UL1500 for marine applications. Their robust design ensures resistance to vibration, shock, thermoshock, moisture, and salt spray, with a temperature range of -40°C to +85°C. Interchangeable actuators allow for easy panel redesign and maximum design variety, while optional plug-in terminal connectors enable pre-wiring of wire harnesses.
Carling Technologies VRT Contura Sealed Rocker Switch Specifications:
- Contact Rating: 0.4VA @ 24VDC (MAX) resistive
- Current Rating: 15 amps, 125VAC
- Voltage Rating: 10 amps, 250VAC
- HP Rating: 1/2 HP 125-250VAC
- DC Voltage Rating: 20 amps, 4-14VDC; 15 amps, 15-28VDC; 10A, 14V
- Dielectric Strength: 1500 Volts RMS
- Insulation Resistance: 50 Megohms
- Initial Contact Resistance: 10 milliohms max
- Sealing: Sealed version: IP66/68
- Temperature Range: -40°C to +85°C
- Actuator: Thermoplastic polycarbonate with nylon or elastomer overlay
- Terminal Options: Eight or ten terminal base styles with AMP & Packard compatible connectors
Buy the VRT CARLING TECHNOLOGIES Contura Sealed Rocker Switch | myMectronic
Purchase the CARLING TECHNOLOGIES VRT Contura Sealed Rocker Switch securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Carling Technologies VRT?
You can click on the BUY or RFQ button to purchase VRT from an authorized Carling Technologies distributor.
How do I troubleshoot issues or seek technical support for part VRT?
You can download the VRT datasheet or visit the Carling Technologies website for support.
Who is the manufacturer of VRT?
Carling Technologies
