E-SWITCH TL1275CA2WA500QPRG tactile switch
The TL1275 series tactile switch offers reliable, multi-application performance with SPST contact arrangement, 50mA @ 12VDC rating, and sharp tactile response. Designed for vandal-resistant, detector, DIP, keylock, navigation, slide, and toggle applications, it features an insulative resistance of 100 MQ min., dielectric strength of 250V RMS, and an operating temperature range of -25°C to 70°C. With a travel of 0.25mm and actuation force of 350 gf, the switch supports a maximum panel thickness of 3.5mm, ensuring durability and consistent tactile feedback.
E-SWITCH TL1275CA2WA500QPRG tactile switch Specifications:
- Contact Arrangement: SPST with 500mm long wire leads with connectors
- Contact Rating: 50mA at 12VDC
- Contact Resistance: 100mΩ Initial
- Insulation Resistance: 100 MQ Min.
- Dielectric Strength: 250V RMS
- Electrical Life: 100,000 cycles
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -25°C to 70°C
- Travel: 0.25mm + 0.1mm
- Actuation Force: 350 gf + 100gf
- Panel Thickness: Max 3.5mm
- Housing Material: Not specified, standard for tactile switches
- Wire Gauge: 26 AWG
- Voltage: 300V, 105°C
- Connector: JSW A2541H-2P
- Terminals: JSW A2547T-GP
Buy the Buy Durable Vandal-Resistant Switch Part Number TL1275CA2WA500QPRG Online
Purchase the TL1275CA2WA500QPRG tactile switch online to ensure durable, high-quality performance in vandal-resistant, detector, DIP, keylock, and navigation applications. Featuring a contact rating of 50mA at 12VDC, 100 MQ insulation resistance, and a travel of 0.25mm, it is built for reliability. With a maximum panel thickness of 3.5mm, this switch supports long-term operation with a sharp tactile response, making it an ideal choice for industrial control, automation, and electronic devices requiring precise actuation and robust construction.
Buy TL1275CA2WA500QPRG now and enjoy high reliability with a tactile response ideal for demanding industrial and navigation applications.
Frequently Asked Questions
Where can I buy E-SWITCH TL1275CA2WA500QPRG?
You can click on the BUY or RFQ button to purchase TL1275CA2WA500QPRG from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part TL1275CA2WA500QPRG?
You can download the TL1275CA2WA500QPRG datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of TL1275CA2WA500QPRG?
E-SWITCH
