E-SWITCH TL6275BA2PQUR Toggle Switch
The TL6275 series toggle switches are robust, anti-vandal, and high-quality switches designed for demanding applications. Featuring SPST contact arrangement with a contact rating of 50mA at 12VDC, these switches offer reliable performance with 100,000 cycles of electrical life and a dielectric strength of 250V RMS. They operate efficiently within a temperature range of -25°C to 70°C, with a travel of 0.25mm and an actuation force of 350 gf. Suitable for various industrial and control applications, they provide durable, water-resistant, PCB-mount termination options with multiple cap and LED color configurations.
E-SWITCH TL6275BA2PQUR Toggle Switch Specifications:
- Contact Arrangement: SPST
- Contact Rating: 50mA @ 12VDC
- Contact Resistance: 100mΩ Initial
- Insulation Resistance: 100 MΩ Min.
- Dielectric Strength: 250V RMS
- Electrical Life: 100,000 cycles
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -25°C to 70°C
- Travel: 0.25mm
- Actuation Force: 350 gf
- Termination: PCB Pins / Thru Hole
- Cap Options: Transparent, Opaque, Translucent, High Square/Circle
- LED Polarity: Identified for LED indicators (+/-)
- Cap Size: 6.00mm, 7.40mm, 9.15mm, 11.15mm
- Dimensions vary with actuator type and cap style
- Durability: Water-wash capable, high cycle life, suitable for vandal-resistant environments
Buy the Buy Bey TL6275 Part Number TL6275BA2PQUR Online
Purchase the Bey TL6275 toggle switch online today and benefit from its durable, vandal-resistant design suitable for industrial control panels. This SPST switch offers 50mA at 12VDC, 100,000 cycle life, and dielectric strength of 250V RMS, ensuring reliable operation in harsh environments. Its PCB mounting with water-wash capability, multiple cap options, and LED polarity identification make it ideal for various control and automation applications. Get this high-quality switch now for increased durability and performance in your next project.
Buy Bey TL6275BA2PQUR toggle switch now and experience unmatched reliability and performance in demanding control environments.
Frequently Asked Questions
Where can I buy E-SWITCH TL6275BA2PQUR?
You can click on the BUY or RFQ button to purchase TL6275BA2PQUR from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part TL6275BA2PQUR?
You can download the TL6275BA2PQUR datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of TL6275BA2PQUR?
E-SWITCH
