E-SWITCH ULV7F23SS311 Anti-Vandal Switch
The ULV7 Series anti-vandal switches are durable, IP67-rated SPDT and DPDT toggle switches designed for harsh environments. Featuring a 3A, 250VAC electrical rating, they support over 1 million mechanical cycles and 50,000 electrical cycles. These vandal-resistant switches are suitable for medical equipment, industrial applications, and control panels, offering illumination options, adjustable actuation force, and various actuator styles. Their robust construction ensures long-lasting performance with a panel thickness compatibility of 1-10mm and a light metal alloy body for reliable operation in demanding conditions.
E-SWITCH ULV7F23SS311 Anti-Vandal Switch Specifications:
- Electrical Rating: 3A, 250VAC
- Mechanical Life: 1,000,000 cycles (momentary); 500,000 cycles (latching)
- Electrical Life: 50,000 Cycles
- Contact Resistance: 50mΩ
- Insulation Resistance: 1000 MΩ @ 500VDC
- Dielectric Strength: 2,000VAC
- Operating/Storage Temperature: -20°C to 55°C
- Travel: 3.2mm
- Moisture Protection: IP67
- Contact Arrangement: SPDT or DPDT
- Actuation Force: Single Pole: 2.5N; Double Pole: 3.5N
- Panel Thickness: 1-10mm
- Hex Nut Torque: 5-14Nm
- Mechanical Impact Protection: IK10
- Agency Approvals: cURus
Buy the Buy ULV7 Series Anti-Vandal Switch Part Number ULV7F23SS311 Online
Order the ULV7 Series anti-vandal switch online now and experience reliable performance in harsh conditions. These IP67-rated switches feature robust construction, support high current loads, and are suitable for industrial, medical, and control panel applications. With options for illumination, various actuator styles, and compliance with safety standards, they ensure long-term durability, operational safety, and ease of installation. Perfect for environments requiring vandal resistance and high reliability, these switches are an essential component for critical systems.
Get ULV7F23SS311 today—built for precision and long-lasting durability in demanding environments.
