E-SWITCH ULV8F2GSS341 Anti-vandal switch
The ULV8F2GSS341 is a vandal-resistant switch designed for rugged applications requiring durability and reliable performance. It features a stainless steel body and lever, providing IP67 moisture protection and withstands up to 1,000,000 mechanical cycles. The switch has a 50,000 electrical cycle life, operates within -20°C to 55°C temperatures, and supports SPDT or DPDT contact configurations. With a travel of 3.2mm and an actuation force of 2.5N (single pole) or 3.5N (double pole), it suits industrial, security, and automation environments demanding high impact resistance and long-lasting operation.
E-SWITCH ULV8F2GSS341 Anti-vandal switch Specifications:
- Electrical Rating: 3A, 125/250VAC
- Mechanical Life: 1,000,000 cycles (momentary), 500,000 cycles (latching)
- Electrical Life: 50,000 Cycles
- Contact Resistance: 50mΩ
- Insulation Resistance: 1000 MΩ @ 500VDC
- Dielectric Strength: 2,000VAC
- Operating Temperature: -20°C to 55°C
- Travel: 3.2mm
- Moisture Protection: IP67
- Contact Arrangement: SPDT or DPDT
- Actuation Force: Single Pole: 2.5N; Double Pole: 3.5N
- Panel Thickness: 1-10mm
- Hex Nut Torque: 5-14Nm
- Agency Approvals: cURus
Buy the Vandal-Resistant Series Anti-Vandal Switch: ULV8F2GSS341
Purchase the ULV8F2GSS341 anti-vandal switch online today for a rugged, high-impact resistant switch engineered for security and industrial applications. Featuring stainless steel construction and IP67 protection, this switch ensures long-lasting durability and reliable operation in demanding environments. With a contact rating of 3A at 125/250VAC, a mechanical lifespan of up to 1,000,000 cycles, and operating temperature range from -20°C to 55°C, it is ideal for automation, security, and heavy-duty applications requiring dependable performance and advanced moisture protection.
Get ULV8F2GSS341 today—built for rugged durability and reliable performance in harsh environments.
Frequently Asked Questions
Where can I buy E-SWITCH ULV8F2GSS341?
You can click on the BUY or RFQ button to purchase ULV8F2GSS341 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part ULV8F2GSS341?
You can download the ULV8F2GSS341 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of ULV8F2GSS341?
E-SWITCH
