EECO 2A212012GF Miniature Timing Relay
The EECO 2A212012GF is a miniature electropneumatic timing relay within the AGASTAT 2100 series. It utilizes a sealed timing head that circulates air under controlled pressure to provide adjustable timing. The relay offers high repeat accuracy over a wide voltage and temperature range, making it suitable for demanding industrial environments. Its snap-action switch assembly and precision-wound solenoid ensure sustained contact pressure and reliable operation. The relay is ideal for applications requiring precise timing control, such as automated machinery, process control systems, and safety circuits.
EECO 2A212012GF Miniature Timing Relay Specifications:
- High Repeat Accuracy: over voltage and temperature extremes
- Hermetically Sealed: designed for high shock and vibration applications
- Instant Recycling: easy linear adjustment
- Dial Head Adjustment: no needle valves
- Delay Ranges: milliseconds to 3 minutes
- Contacts: DPDT
- Reset Time: 2112 Series: 25 msec.; 2122 Series: 75 msec.
- Relay Release Time: 25 msec. (2112 Series)
- Relay Operate Time: 75 msec. (2122 Series)
- Operating Voltage: See table for details
- Dielectric: 1000V RMS @ 60Hz between non-connected terminals
- Contact Rating (DPDT Contacts): See table for details
- Ambient Temperature Range: -55°C to +85°C
- Weight: Maximum, any unit - 17 ozs.
- Mounting/Terminals: Chassis mounting tabs, octal plugs, solder hook terminals, panel mounting back plate
