Eaton Bussmann EM220504 PCB Terminal Block
The EuroMag Series PCB terminal blocks offer a versatile, modular design ideal for PCB applications. Featuring 45° angled connectors with 5.00mm center spacing, these terminal blocks support wire ranges from #12 to 24 AWG. Made from durable grey polyamide 6/6 with UL 94V-0 certification, they ensure safety and reliability. Constructed with tin-plated brass contacts and cages, they provide excellent conductivity and corrosion resistance. Suitable for operating temperatures up to 105°C, these terminal blocks are perfect for automation and control systems requiring secure, compact, and easy-to-assemble connections.
Eaton Bussmann EM220504 PCB Terminal Block Specifications:
- Rating: 10A, 300V
- Center Spacing: 0.197 inches (5.00mm)
- Wire Range: #12-24 AWG
- Housing Material: Grey Polyamide Type 6/6, 94V-0
- Contact Material: Brass Tin-Plated
- Cage Material: Brass, Tin-Plated
- Screw Size: M2.6 Zinc-Plated Steel
- Operating Temperature: -33°C to 105°C (221°F)
- Torque Rating: 3.5 Ib-in.
- Recommended PCB Hole Diameters: 0.055 inches (1.40mm)
- Construction: Modular with dovetail interlocking for longer lengths
- Agency Certifications: UL, CE (File E62622)
Buy the Buy Eaton EuroMag Terminal Blocks Part Number EM220504 Online
Enhance your electronic projects with the Eaton EuroMag Terminal Block series featuring 45° angled, modular design, supporting #12-24 AWG wire. Made from high-quality, UL 94V-0 rated grey polyamide, these terminal blocks provide excellent durability, insulation, and efficient electrical conductivity thanks to tin-plated brass contacts. Suitable for operating temperatures up to 105°C, they are ideal for automation, control panels, and PCB wiring. Easy to install with recommended hole sizes, these blocks ensure safe, reliable, and organized connections which streamline assembly and maintenance.
Order your Eaton EuroMag Series EM220504 terminal block today and ensure reliable PCB connections with robust modular design and high-temperature performance.
Frequently Asked Questions
Where can I buy Eaton Bussmann EM220504?
You can click on the BUY or RFQ button to purchase EM220504 from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part EM220504?
You can download the EM220504 datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of EM220504?
Eaton Bussmann
