Eaton Bussmann LPCC15 Low-Peak Fuse
The LP-CC-15 is a 15A Low-Peak™ Class CC time-delay fuse offering optimal protection for small motor and relay circuits. It features dual-element, time-delay design with a 200kA interrupting rating, ensuring reliable surge and short-circuit protection. Its compact, space-saving form includes a rejection tip, preventing incorrect fuse insertion and ensuring safe operation. Designed to simplify inventory management and foster easy selective coordination with a 2:1 amp ratio, it complies with NEC standards for high-capacity systems. Ideal for industrial applications, it protects downstream components from thermal and magnetic damage caused by short circuits and overloads.
Eaton Bussmann LPCC15 Low-Peak Fuse Specifications:
- Voltage Rating: 600Vac or less
- Current Rating: 15A
- Time-Delay: ≥10 seconds at 500% rated amps
- Interrupting Rating: 200kA RMS Sym.
- Poles: 1-pole (gangable)
- Dimensions: See page 1-6 for Class CC dimensions
- Construction: Dual-element, time-delay fuse
- Agency Certification: UL Listed Guide JDDZ, CSA Certified Class 1422-02
- Features: Rejection tip to prevent incorrect insertion, space-saving footprint, high current limiting, suitable for industrial applications
- Standards: NEC compliant, space efficient, easy selective coordination
Buy the Bussmann Series LPCC Series Low-Peak Class CC Fuse: LPCC15
Order the Bussmann Series LPCC15 fuse online now to get a space-saving, high-performance protection component for your motor and relay circuits. This 15A low-peak, class CC fuse offers rapid surge response and a 200kA interrupting rating, ensuring safe and reliable operation in industrial environments. Its dual-element, time-delay design helps prevent overload damage while maintaining precise protection coordination with other system components. Easy to install, it reduces inventory complexity, prevents incorrect fuse insertion with a rejection tip, and provides maximum circuit safety—ideal for power panels, industrial machinery, and control systems. Secure your system’s reliability today by purchasing online.
Buy Bussmann Bussmann Series LPCC15 low-peak fuse now and experience unmatched reliability and space-saving performance for industrial motor protection.
Frequently Asked Questions
Where can I buy Eaton Bussmann LPCC15?
You can click on the BUY or RFQ button to purchase LPCC15 from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part LPCC15?
You can download the LPCC15 datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of LPCC15?
Eaton Bussmann
