FINDER 222382304000 Power Relay
This power relay features a single normally closed and normally open contact, rated for 20A at 240V AC, with silver tin oxide contacts for enhanced durability. Designed for industrial switching applications, it provides reliable operation with reinforced insulation and continuous duty for coil and contacts. The relay supports various load types, including resistive and inductive loads. It comes with a 240V AC coil, mechanical and LED indicators, and is protected against electrical transients, making it suitable for automation and control systems requiring robust, high-current switching capabilities.
FINDER 222382304000 Power Relay Specifications:
- Rated current: 20A
- Rated voltage: 240V AC
- Contact material: AgSnO2 (silver tin oxide)
- Contact configuration: 1 NO + 1 NC
- Maximum peak current: 120A
- Rated load: 6,250 VA
- Insulation: Reinforced insulation between coil and contacts
- Coil voltage: 240V AC
- Coil power consumption: 2 VA
- Mechanical life: 2-108 cycles
- Electrical life at rated load: 30-10 cycles
- Operate/release time: 30/20 ms
- Protection category: 1P20
- Ambient temperature range: -20°C to +50°C
- Dielectric strength: 4,000 V across coil and contacts
- Insulation between contacts: 3 mm contact gap for NO.
- Overvoltage category: UL equivalent Category I
Buy the Finder Series 22 Power Relay: 222382304000
Secure your automation system with the Finder power relay featuring 20A rated current at 240V AC, durable silver tin oxide contacts, reinforced insulation, and reliable operation. Designed for various industrial loads, it offers high peak current capacity, rapid switching, and robust construction. Easy to install with screw terminal connections, LED and mechanical indicators for status, and protection against electrical transients, making it an excellent choice for controlling high-current circuits efficiently and safely.
Buy Finder 222382304000 power relay now and experience unmatched reliability and durable high-current switching for industrial automation.
Frequently Asked Questions
Where can I buy FINDER 222382304000?
You can click on the BUY or RFQ button to purchase 222382304000 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 222382304000?
You can download the 222382304000 datasheet or visit the FINDER website for support.
Who is the manufacturer of 222382304000?
FINDER
