FINDER 385100120060 Electromechanical Relay
The electromechanical relay series offers versatile 1 pole and 2 pole configurations with screw and screwless terminal options, suitable for PLC and electronic systems. Rated for 6A or 16A with UL listing and 35 mm rail mounting, these relays feature integral coil indication, protection circuits, and instant relay ejection. Available in sensitive DC or AC/DC coil versions, they provide high electrical life, silent operation, and reliable switching for resistive loads up to 250V AC/DC, ideal for automation and control applications.
FINDER 385100120060 Electromechanical Relay Specifications:
- Contact configuration: 1 CO (SPDT) or 2 CO (DPDT)
- Rated current: 6A or 16A, maximum peak current: 10A
- Rated voltage: 250VAC/400VDC maximum
- Rated load: 1500 VA for AC or 2000 VA for DC
- Contact material: Silver Nickel (AgNi)
- Coil voltage options: 12V, 24V, 48V, 60V, 110V...125V, 220V...240V AC/DC
- Mechanical life: 10^8 cycles; Electrical life at rated load: 60^8 cycles
- Operate/Release time: approx. 8/10 ms
- Insulation voltage: 250VAC, impulse withstand voltage: 4 kV
- Mounting: 35 mm EN 60715 rail, high resistance to vibration and vibration
- Ambient temperature: -40°C to +70°C
- Protection class: IP20
Buy the Finder Series 38 Electromechanical Relay: 385100120060
Discover the reliable Finder Series 38 electromechanical relay designed for automation and control systems. With a maximum current of 16A, UL listing, and compact 35 mm rail mounting, this relay offers high electrical life, silent operation, and versatile screw or screwless terminals. Its integral coil indication and protection circuit ensure safe and efficient switching across resistive loads up to 250V AC/DC. Perfect for PLC integration, industrial automation, and robotics, order online today for quick, secure delivery to elevate your projects.
Order your Finder Series 38 electromechanical relay with 16A capacity today and give your projects the dependable quality they deserve.
