FINDER 202882300000 Industrial Control Relay
This 230 VAC sequencing relay features a 2-pole, DPST-NO contact configuration and is designed for DIN rail mounting. It supports up to 16 Amps and is suitable for controlling single-phase and double-phase loads with multiple switching sequences. Equipped with test buttons, mechanical indicators, and options for illuminated push-button connections, the relay offers versatile installation options. Made with cadmium-free contacts, it complies with safety standards and provides reliable switching performance across various industrial applications, ensuring efficient control of electrical circuits.
FINDER 202882300000 Industrial Control Relay Specifications:
- Type: Double pole, double-throw (DPST-NO)
- Rated Current: 16 Amps
- Maximum Peak Current: 30 Amps
- Rated Voltage: 250 V AC / 400 V AC
- Maximum Switching Voltage: 250 V AC
- Rated Load AC1: 4,000 VA
- Rated Load AC15 (230 V): 750 VA
- Coil Voltage: 230 V AC
- Insulation Between Coil and Contacts: 4 kV
- Ambient Temperature Range: -40°C to +70°C
- Protection Category: IP 20
- Mechanical Life: 300,000 cycles
- Electrical Life at Rated Load: 100,000 cycles
- Power Dissipation (Rated): 1.3 W
- Contact Material: Cadmium-free (AgNi or AgSnO2 options)
- Relay Mounting: 35 mm DIN rail (EN 60715)
- Approval: UL rated, complies with EN standards
Buy the Finder Series 20 Relay: 202882300000
Order the Finder 202882300000 relay online today and experience reliable, high-performance switching for industrial automation. Designed for DIN rail mounting and rated at 230 volts AC, this relay supports up to 16 amps, making it ideal for controlling single-phase and double-phase loads with various switching sequences. Its cadmium-free contacts ensure safety and environmental compliance, while features like test buttons and mechanical indicators simplify installation and troubleshooting. Enhance your control system with this durable, UL-rated relay now for seamless automation.
Get Finder 202882300000 today—built for precision and long-lasting durability in industrial control applications.
Frequently Asked Questions
Where can I buy FINDER 202882300000?
You can click on the BUY or RFQ button to purchase 202882300000 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 202882300000?
You can download the 202882300000 datasheet or visit the FINDER website for support.
Who is the manufacturer of 202882300000?
FINDER
