FINDER 222182304000 Power Relay
This power relay features a single-pole, normally open contact configuration with a 20A current rating and operates on a 240V AC coil. It utilizes AgSnO2 contacts for enhanced switching reliability and durability, making it suitable for automation and industrial control applications. The relay's robust design includes reinforced insulation and a contact gap greater than 3 mm, ensuring safe operation under high inrush loads. It is ideal for controlling lamps, resistive loads, and motor circuits, with mechanical and LED indicators for status monitoring.
FINDER 222182304000 Power Relay Specifications:
- Contact configuration: SPST-NO
- Rated current: 20 A
- Rated voltage: 240 VAC
- Rated load: AC1 / AC7a VA 6,250
- Maximum peak current: 80 A
- Coil voltage: 240 V AC
- Coil power consumption: 2 VA
- Operating range: 0.8 ... 1.1 Un
- Holding voltage: 0.4 Un
- Drop-out voltage: 0.1 Un
- Mechanical life: 2 x 10^8 cycles
- Electrical life at rated load: 30 x 10^4 cycles
- Contact gap: > 3 mm
- Insulation: Reinforced between coil and contacts
- Dielectric strength: 4,000 VAC
- Ambient temperature: -20°C to +50°C
- Protection category: IP20
- Material: Silver Tin Oxide (AgSnO2)
- Approval: EN 61095: 2009
Buy the Finder Series 22 Power Relay: 222182304000
Purchase the Finder power relay online and enjoy reliable switching for high inrush loads with a 20A current rating and 240V AC coil. Designed for industrial automation, this relay features AgSnO2 contacts for enhanced durability and switch performance. Its reinforced insulation and contact gap ensure safe operation in demanding environments. With mechanical and LED indicators, easy installation, and compliance with EN 61095: 2009 standards, this relay guarantees long-term dependable service for controlling lamps, motors, and resistive loads. Buy now for efficient industrial control.
Get Finder 222182304000 today—built for precision and long-lasting durability in industrial switching applications.
Frequently Asked Questions
Where can I buy FINDER 222182304000?
You can click on the BUY or RFQ button to purchase 222182304000 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 222182304000?
You can download the 222182304000 datasheet or visit the FINDER website for support.
Who is the manufacturer of 222182304000?
FINDER
