Harting 09110012751 High-current industrial connector
The Han 1HC-bu-AX is a high-current electrical connector insert designed for industrial applications, supporting a rated current of 350A and voltage of 2,000 V. Made from durable polycarbonate and polyamide, it features axial screw termination for reliable connection and resistance to vibration and shock. Suitable for conductor cross-sections from 5 to 70 mm², it ensures secure fixing with specified tightening torques. Its robust design and compliance with UL 94V-0 flammability standards make it ideal for demanding industrial environments, offering excellent electrical and mechanical performance.
Harting 09110012751 High-current industrial connector Specifications:
- Conductor cross-section: 5... 70 mm²
- Wire outer diameter: ≤19.5 mm
- Rated current: 350A
- Rated voltage: 2,000 V
- Rated impulse voltage: 12 kV
- Pollution degree: 3
- Insulation resistance: >10^9 Ω
- Contact resistance: <0.2 mΩ
- Stripping length: 9... 20 mm
- Tightening torque: 8 Nm @ 35 mm, 10 Nm @ 50 mm, 12 Nm @ 70 mm
- Vibration resistance: Category 2 IEC 61373
- Shock resistance: Category 2 IEC 61373
- Material (insert): Polycarbonate
- Material (contacts): Copper alloy, silver plated
- Flammability class: UL 94V-0
- Operating temperature: -40°C to +125°C
- Number of mating cycles: 2,500
Buy the Buy HARTING Connector Part Number 09110012751 Online
Purchase the HARTING connector part number 09110012751 online today and enjoy top-tier quality, exceptional current handling capacity of 350A, and robust design suitable for demanding industrial environments. Made from durable polycarbonate and copper alloy, it ensures reliable electrical connections with comprehensive specifications including voltage ratings of 2,000 V and impulse voltage of 12 kV. Easy to install with specified tightening torques, this connector offers long-lasting performance, high vibration and shock resistance, making it an essential component for industrial control systems and automation equipment.
Buy HARTING 09110012751 high-current connector now and experience unmatched reliability, mechanical durability, and electrical safety for industrial applications.
Frequently Asked Questions
Where can I buy Harting 09110012751?
You can click on the BUY or RFQ button to purchase 09110012751 from an authorized Harting distributor.
How do I troubleshoot issues or seek technical support for part 09110012751?
You can download the 09110012751 datasheet or visit the Harting website for support.
Who is the manufacturer of 09110012751?
Harting
