Harting 09694115136 D-Sub Connector
The D-Sub M series mixed cable connector features both male and female connectors with mixed shells and pre-mounted signal solder cup contacts. Available with 36 or 43 contacts, it supports S4 and PL3 performance levels and uses solder cup termination for secure connections. Ideal for applications in communications and networking, computers and peripherals, and industrial environments.
Harting 09694115136 D-Sub Connector Specifications:
- Number of contacts: 36 or 43
- Shell: mixed shells with pre-mounted signal solder cup contacts
- Performance levels: S4 and PL3
- Termination type: Solder cup
- Contact plating: 0.76 μm Au over Ni for signal contacts
- Material: Thermoplastic resin, glass-fiber filled (UL 94-VO), plated steel shell
- Operating temperature: -55 °C to +125 °C
- Approval standards: DIN 41652, MIL-C 24 308
- Current rating: 5 A for signal contacts
- Body color: Green for standard, black for crimp
- Physical dimensions vary per contact count (approximate length: 38.5–55.3mm); precise measurements available on datasheets.
Buy the HARTING Series D-Sub Mixed Cable Connectors: 09694115136
Enhance your electronic connectivity with our reliable D-Sub connector range. Featuring mixed shells and pre-mounted signal solder cup contacts, these connectors support up to 43 contacts with high-level performance standards. Perfect for industrial, communication, and networking solutions, they ensure secure soldered connections with corrosion-resistant gold plating. Available in various sizes, they are designed with robust thermoplastic bodies and steel shells, operating efficiently in demanding temperature ranges. Easily integrate these connectors into your existing systems for improved durability and performance.
Order your HARTING Series D-Sub 36/43 Contact Cable Connector today and give your industrial and communication projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy Harting 09694115136?
You can click on the BUY or RFQ button to purchase 09694115136 from an authorized Harting distributor.
How do I troubleshoot issues or seek technical support for part 09694115136?
You can download the 09694115136 datasheet or visit the Harting website for support.
Who is the manufacturer of 09694115136?
Harting
