Harting 21033411505 M12 Panel Feed Through Connector
The HARTING 21 03 341 1505 is a M12 panel feed through connector designed for secure and reliable data and power transmission in industrial environments. Its robust construction, featuring a zinc die-cast housing and polyamide insert, provides excellent protection against harsh conditions. The B-coding and IP67 rating ensure compatibility and environmental resistance, making it suitable for applications in automation, control systems, and power distribution. The gold-plated copper alloy contacts provide low contact resistance and excellent signal integrity.
Harting 21033411505 M12 Panel Feed Through Connector Specifications:
- Part Number: 21 03 341 1505
- M12-M panel feed through: 5pol.B-cod.IP67
- Category: Connector
- Series: Circular connectors M12
- Element: PCB adapter
- Specification: Straight
- Termination method: Reflow soldering termination (THR/SMC)
- Gender: Male
- Locking type: Screw locking
- Shielding: Shielded
- Number of contacts: 5
- Coding: B-coding
- Rated current: 4 A
- Rated voltage: 50 V
- Rated impulse voltage: 1.5 kV
- Pollution degree: 3
- Insulation resistance: > 10 Ω
- Contact resistance: ≤10 mΩ
- Ambient temperature: -40 ... +85 °C
- Mating cycles: ≥100
- Degree of protection: IP67
- Overvoltage category: III
- Material (insert): Polyamide
- Material (contacts): Copper alloy
- Surface (contacts): Gold plated
- Material (hood/housing): Zinc die-cast
- RoHS: compliant with exemption
- RoHS exemptions: 6c: Copper alloy containing up to 4 % lead by weight
- ELV status: compliant with exemption
- China RoHS: 50
- REACH Annex XVII substances: No
- REACH ANNEX XIV substances: No
- REACH SVHC substances: Lead
- Packaging size: 1
- Net weight: 22.9 g
- Country of origin: Romania
- European customs tariff number: 85365080
- eCl@ss: 27440402 PCB connector
