Honeywell DTE62RN Medium-Duty Limit Switch
The DTE6-2RN is a double-pole double-throw medium-duty limit switch with a sealed side-mount design and epoxy-coated zinc housing. It features a seal boot plunger actuator with a combined insulator and cemented seal for durable operation in harsh environments, including exposure to liquids or particulates. The compact enclosure allows installation in limited spaces. It supports momentary or maintained contact, a grounding screw for safety, and various termination options such as conduit threads, mini connectors, or wired cables. This switch handles electrical loads up to 15A or 22A depending on model, with a temperature range from -40°C to 71°C and certifications including UL and CSA, making it ideal for industrial machinery and transportation applications.
Honeywell DTE62RN Medium-Duty Limit Switch Specifications:
- Housing Material: Electrostatic epoxy coated zinc
- Actuator Type: Seal boot plunger with seal and insulator inside enclosure
- Electrical Ratings: 15A or 22A, support for SPDT and DPDT contacts
- Conduit Thread Sizes: 0.5-14 NPT, M20 x 1.5 mm optional
- Operating Temperature Range: -40°C to 71°C (-40°F to 160°F)
- Mechanical Endurance: Up to 5 million cycles for standard switches
- Electrical Endurance: Up to 50,000 cycles at full rated load
- Certifications: UL, CSA
- Termination Options: Conduit thread, mini connector, four-conductor PVC cable
- Dimensions: Approx. 69.1 mm (2.72 in) length, design suited for limited space installation
Buy the Buy Honeywell Limit Switch Part Number DTE62RN Online
Purchase the Honeywell DTE6-2RN limit switch online today to ensure robust and reliable performance in harsh industrial environments. This durable switch features epoxy-coated zinc housing, sealed actuator with a boot, and supports a variety of termination options including conduit threads and wired cables. Its compact size allows installation in limited spaces, making it ideal for machinery, transportation, and agricultural equipment exposed to liquids, dust, or extreme temperatures. With high electrical and mechanical endurance and global certifications, this switch guarantees long-lasting service and safety for your critical applications.
Order your Honeywell SeriesDTE62RN double-pole limit switch today and ensure reliable operation for demanding industrial and outdoor environments.
Frequently Asked Questions
Where can I buy Honeywell DTE62RN?
You can click on the BUY or RFQ button to purchase DTE62RN from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part DTE62RN?
You can download the DTE62RN datasheet or visit the Honeywell website for support.
Who is the manufacturer of DTE62RN?
Honeywell
