Honeywell NGCPA50AX32A1A Medium-Duty Limit Switch
Honeywell's MICRO SWITCH NGC Series offers configurable medium-duty limit switches designed for indoor and outdoor use, sealed to IP67. These switches support SPDT and DPDT circuitry, with high vibration and shock ratings, broad current capacity of 10 A, and various actuator options. They are suitable for demanding applications like elevators, machine tools, rail doors, and packaging equipment. The series provides global approvals, electrical reliability, and a versatile platform that simplifies design and sourcing for harsh environments.
Honeywell NGCPA50AX32A1A Medium-Duty Limit Switch Specifications:
- Housing Material: Metal and plastic options
- Sealing: IP67 per IEC 60529
- Operating Temperature: -25°C to 75°C
- Storage Temperature: -40°C to 85°C
- Mechanical Endurance: 5 million cycles minimum
- Electrical Life: 500,000 cycles at rated loads
- Rated Voltage & Current: AC15 up to 120 V 6 A, DC13 up to 125 V 0.55 A
- Contacts: Snap action, positive break, silver alloy or gold-plated
- Switching Options: SPDT, DPDT
- Shock Resistance: 50 g for 11 ms
- Vibration Resistance: 10 g
- Certifications: UL, CE, cUL, CCC
- Connection Types: Cable, connector, panel-mount options
- Actuator Types: Side rotary, plunger, roller lever, cross roller plunger
- Operating Speed: 0.3 mm/s to 2 m/s
- Dielectric Strength: 1890 Vac (metal), 2890 Vac (plastic)
- Impulse Voltage: 2500 Vde
- Pollution Degree: 3D
- Humidity: Up to 95% RH
Buy the Honeywell Series NGC Limit Switch: 002409
Explore the Honeywell MICRO SWITCH NGC Series, a versatile and robust limit switch designed for challenging indoor and outdoor applications. With IP67 sealing and high shock and vibration ratings, these switches support both SPDT and DPDT circuitry, ensuring optimal performance across a wide range of industrial uses such as elevators, rail doors, and packaging equipment. Their flexible actuator options, global approvals, and high durability make them an excellent choice for engineers seeking reliable, standardized solutions in demanding environments. Purchase online for fast delivery and expert support.
Buy Honeywell 002409 now and experience unmatched reliability and performance in harsh industrial environments.
