Honeywell PX2AF1XX200PSAAX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducer is a configurable pressure sensor designed for robust performance in harsh conditions. Featuring piezoresistive sensing technology and ASIC signal conditioning, it delivers a Total Error Band of ±2% over a wide temperature range. Compatible with various media and offering ingress protection up to IP69K, the PX2 Series is ideal for industrial applications such as compressor monitoring, HVAC/R systems, and factory automation. Its affordability, availability, and high durability make it a compelling choice for system integration.
Honeywell PX2AF1XX200PSAAX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 46 bar, 100 kPa to 4.6 MPa, 15 psi to 667 psi
- Operating Temperature Range: -40 ºC to 125 ºC [-40 °F to 257 °F]
- Total Error Band (TEB): ±2%
- Connector Types: Delphi Metri-Pack 150, Micro M12, DIN, Deutsch, cable harness (1 m, 2 m, 3 m, or 5 m)
- Port Types: 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF SAE J1926-3, 7/16-20 UNF SAE J1926-3, 1/4 in 45° Flare Female Schrader (7/16-20 SAE J512), M12 x 1.5 ISO 6149-3, G1/4 ISO 1179-3, G1/8 ISO 1179-3
- Pressure Reference: Absolute or sealed gage
- Output Transfer Function: Ratiometric, regulated or current
- Response Time: <2 ms
- Cycle Life: Minimum 10 million cycles to operating pressure
- Ingress Protection: Up to IP69K
- Radiated Immunity: 100 V/m
- Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
Buy the PX2AF1XX200PSAAX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2AF1XX200PSAAX Heavy Duty Pressure Transducer securely and reliably through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell PX2AF1XX200PSAAX?
You can click on the BUY or RFQ button to purchase PX2AF1XX200PSAAX from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part PX2AF1XX200PSAAX?
You can download the PX2AF1XX200PSAAX datasheet or visit the Honeywell website for support.
Who is the manufacturer of PX2AF1XX200PSAAX?
Honeywell
