Hammond Manufacturing 14449 aluminum chassis
The Aluminum Chassis 1444 Series by Hammond Manufacturing features heavy-duty spot-welded construction with a natural aluminum finish. It includes solid walnut side panels that attach with machine screws and lockwashers, enhancing both aesthetics and durability. The chassis offers a compact, inset mounting surface, reducing usable surface area by approximately 7/8 inch. Available in multiple sizes with optional bottom panels, this chassis is suitable for electronic enclosures requiring sturdy and attractive metal housing with customizable options and easy assembly.
Hammond Manufacturing 14449 aluminum chassis Specifications:
- Material: Aluminum with walnut side panels
- Aluminum Thickness: 0.04 to 0.05 inches depending on model
- Construction: Spot welded heavy-duty chassis
- Finish: Natural aluminum or painted steel (steel not included)
- Side Panels: Solid walnut, routed, attaches with machine screws
- Mounting: Inset mounting surface, reduces usable space by 7/8 inch
- Bottom Plates: Optional, punched with 4 holes, 3/16 inch diameter
- Hardware: Includes lockwashers, screws should not be torqued past 50 cN.m
- Sizes: Ranges from 4x4 inches up to 17x17 inches in length/width
- Additional: Compatibility excludes steel covers, multiple size options available
Buy the Buy Hammond Aluminum Chassis 1444 Series Part Number 14449 Online
Secure your electronics project with Hammond's Aluminum Chassis 1444 Series, available in multiple sizes with solid walnut sides for an attractive and durable enclosure. Easy to assemble with pre-punched holes, these spot-welded enclosures provide robust protection for sensitive components. Ideal for DIY, prototyping, or professional applications requiring high-quality metal housing, the 1444 Series combines strength, aesthetic appeal, and customization options including optional bottom plates and walnut side panels. Order online today for fast, reliable delivery!
Get Hammond Manufacturing Aluminum Chassis 1444 Series today—designed for sturdy, reliable electronic enclosures with elegant walnut side panels.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 14449?
You can click on the BUY or RFQ button to purchase 14449 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 14449?
You can download the 14449 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 14449?
Hammond Manufacturing
