Hammond Manufacturing 1457C801E Industrial Aluminum Enclosure
This enclosure features a powder-painted aluminum box with stainless steel end panels, designed for industrial applications. It provides IP65 protection, EMI/RFI shielding, and customization options like milling and drilling. The unit measures 26.4475 mm in height, 88.39 mm in width, and 79 mm in depth, with a face-to-face dimension of 41 mm. It includes self-adhesive rubber feet, gaskets, and is available in STEP or IGES models. Ideal for electronics protection, offering durability and corrosion resistance in demanding environments.
Hammond Manufacturing 1457C801E Industrial Aluminum Enclosure Specifications:
- Material: Extruded Aluminum 6063
- End Panels: Type 380 Diecast Aluminum with black powder paint
- Protection: IP65, EMI/RFI shielding
- Dimensions: Height 26.4475 mm, Width 88.39 mm, Depth 79 mm, face-to-face 41 mm
- Tolerance: Aluminum extrusion -/+ 0.02 inch
- Finish: Clear anodized box, black powder painted end panels
- Assembly includes: Box, end panels, stainless steel screws, rubber feet, gaskets, O-rings
- Internal recess for labels/keypads: 0.75 mm (.030 inch)
- Environmental: Suitable for factory modifications including milling, drilling
- Certifications: IP65, EMI/RFI shielding
Buy the Hammond 1457C801E – Reliable Aluminum Enclosure for Industrial Applications
Purchase the Hammond 1457C801E aluminum enclosure online to ensure your electronic devices are protected with IP65 rated waterproof and corrosion-resistant housing. Crafted from extruded aluminum with black powder painted end panels, it offers superior EMI/RFI shielding, durability, and ease of factory modifications like milling and drilling. This enclosure includes stainless steel screws, rubber feet, gaskets, and O-rings for complete assembly, making it ideal for industrial, automation, and control projects. Order now for fast delivery and reliable protection.
Get Hammond 1457C801E today—built for durability and customizable protection in industrial environments.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 1457C801E?
You can click on the BUY or RFQ button to purchase 1457C801E from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 1457C801E?
You can download the 1457C801E datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 1457C801E?
Hammond Manufacturing
