Hammond Manufacturing 160D10 Low Voltage Isolation Transformer
The 160D10 is a low-voltage PCB-mount isolation transformer rated at 1 VA. It features a center-tapped secondary of 10 V at 90 mA in series configuration and 5 V at 180 mA in parallel configuration (RMS). The transformer has a dual primary voltage of 115/230V at 50/60Hz, and utilizes a vertical-mount split bobbin design. It includes non-concentrically wound dual secondary windings, resulting in low primary-to-secondary coupling and eliminating the need for an electrostatic shield. The device provides high insulation with a hi-pot withstand voltage of 2000 Vrms and is rated for 130°C Class-B insulation. It is suitable for power management and industrial applications.
Hammond Manufacturing 160D10 Low Voltage Isolation Transformer Specifications:
- Power Rating: 1 VA
- Primary Voltage: 115/230V at 50/60Hz
- Secondary: 10 V at 90 mA (series), 5 V at 180 mA (parallel)
- Construction: Vertical-mount, split bobbin design
- Winding Type: Dual secondary, non-concentrically wound
- Coupling: Low primary-to-secondary coupling, no electrostatic shield needed
- Insulation: High insulation, rated for 130°C class B
- Hi-pot Voltage: 2000 Vrms
- Size: Compact PCB-mount form factor
- Application: Power management, industrial control
Buy the Buy Hammond Low Voltage PCB Mount Transformer Part Number 160D10 Online
Purchase the Hammond 160D10 low-voltage PCB-mount isolation transformer online today. Engineered for precise power isolation, it features dual primary voltages and a high insulation rating of 2000 Vrms. Its split bobbin, vertical-mount design ensures easy installation in industrial control systems. Rated at 1 VA, it provides reliable secondary configurations of 10 V at 90 mA or 5 V at 180 mA, suitable for various power management needs. Secure your power solutions with this high-quality, durable transformer now.
Get Hammond 160D10 today—built for accurate power isolation and long-lasting durability in industrial applications.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 160D10?
You can click on the BUY or RFQ button to purchase 160D10 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 160D10?
You can download the 160D10 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 160D10?
Hammond Manufacturing
