Hammond Manufacturing 160E16 Low Voltage Power Transformer
This power transformer is ideal for low voltage industrial and control applications, offering multiple output voltages and high insulation. It features a split bobbin vertical mount design, dual winding secondaries, and options for economical single or universal dual primary voltages. Certified by CSA and UL for safety and reliability, it supports a wide range of voltages from 5V to 120VAC RMS, with VA sizes from 0.5 to 24 VA. Its durable construction ensures consistent performance in demanding electrical environments.
Hammond Manufacturing 160E16 Low Voltage Power Transformer Specifications:
- Power Rating: 0.5 to 24 VA
- Input Voltage: 115V or 115/230V dual primary options
- Output Voltages: 5V, 6.3V, 8V, 10V, 12.6V, 14V, 17V, 20V, 28V, 34V, 40V, 56V, 60V
- Output Current: Ranges from 50mA to 2A depending on model
- Insulation: Class B (130°C), Hipot of 2000V RMS
- Construction: Vertical mount, split bobbin, dual wound secondary
- Certifications: CSA approved (LR3902), UL recognized (E50394)
- Dimensions: Variable per model, generally compact sizes suitable for PCB mounting
- Frequency: 50/60Hz
- Environmental: Designed for industrial applications with high insulation standards
Buy the Buy Hammond Low Voltage Power Transformer Part Number 160E16 Online
Order the Hammond 160E16 low voltage power transformer online today and benefit from exceptional durability, high insulation, and versatile output options. Its reliable design ensures consistent operation across various industrial applications. Certified by CSA and UL for safety, this transformer offers peace of mind and proven performance. With a compact vertical mount structure and multiple voltage and current configurations, it provides an excellent solution for control panels and electrical systems. Purchase now for fast delivery and trusted quality from Hammond Manufacturing.
Buy Hammond 160E16 now and experience unmatched reliability and performance in your power management systems.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 160E16?
You can click on the BUY or RFQ button to purchase 160E16 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 160E16?
You can download the 160E16 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 160E16?
Hammond Manufacturing
