Hammond Manufacturing 162F36 Datasheet & Stock
The 162F36 is a 6VA low-voltage PCB-mount isolation transformer featuring a dual primary of 115/230V and a 36V center-tapped secondary with 0.17A current in series configuration and 0.34A in parallel. It operates at 50/60Hz, designed with a low-profile split bobbin core and non-concentrically wound secondary windings. All windings are necessary for proper function. The transformer offers low primary-to-secondary coupling, eliminating the need for an electrostatic shield, and provides high insulation with a Hi-pot rating of 2500 Vrms. It is constructed with 130°C Class-B insulation suitable for power management and industrial applications.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 162F36?
You can click on the BUY or RFQ button to purchase 162F36 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 162F36?
You can download the 162F36 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 162F36?
Hammond Manufacturing
