Hammond Manufacturing 164E16 Power Transformer
This component is designed for power management and industrial applications, providing reliable performance in various electronic systems.
Hammond Manufacturing 164E16 Power Transformer Specifications:
- Power rating: 16V CT at 8A, 8V at 1.6A; 20V CT at 1A, 10V at 2A; 24V CT at 8A, 12V at 1.6A; 28V CT at 1.44A, 14V at 2.6A; 36V CT at 1A, 18V at 2A
- Primary voltages: 115V or 115/230V dual primary options, 50/60Hz operation
- Output voltages: 8V, 10V, 12V, 14V, 18V, 24V, 28V, 36V with corresponding current ratings
- Insulation: High insulation, Hipot 2,500V RMS
- Construction: Low profile, split bobbin design, dual windings, non-concentrically wound
- Mounting: PCB mount with industry standard pin spacing; no hardware needed for smaller sizes, four-hole mounting on larger sizes
- Temperature: Class B insulation, 130°C rated
- Dimensions: Lengths range from 1.38 inches to 2.63 inches, height from 0.25 inches to 1.56 inches, width from 0.25 inches to 0.40 inches
- Certification: UL and ULus recognized, meeting safety standards
- Features: Low primary to secondary coupling, economical single or dual primary configurations, suitable for various power applications
Buy the Hammond Series 162 16V Power Transformer: 164E16
Get your Hammond Series 162 power transformer online today. Designed for industrial and electronic systems, it offers robust performance, high insulation, and dual primary options. With multiple output voltages and current ratings, this compact PCB mount component guarantees dependable power conversion, ensuring safety and efficiency in your projects. Perfect for various power management applications, the 164E16 transformer is easy to install, UL recognized, and built to meet strict safety standards. Don't miss the chance to enhance your system's performance—buy now online!
Order your Hammond Series 162 164E16 power transformer today and ensure reliable power management for your industrial and electronic projects.
