Hammond Manufacturing 164E36 Power Transformer
This component is suitable for applications in power management and industrial systems, providing reliable performance in demanding environments. It features a low profile split bobbin design, dual winding secondaries, and high insulation ratings. Available in various voltages from 5V to 36V with primary options of 115V or 115/230V, it operates on 50/60 Hz. The series offers models ranging from 1.1 VA to 36 VA, with UL recognition, high insulation standards, and industry-standard pin spacing for PC board mounting, ensuring durability and efficiency.
Hammond Manufacturing 164E36 Power Transformer Specifications:
- Power ratings from 1.1 VA to 36 VA
- Input voltage options: single 115V or dual 115/230V primary
- Output voltages: 5V to 36V RMS, CT secondary
- Operating frequency: 50/60 Hz
- High insulation: Hipot 2,500V RMS
- Class B insulation: 130°C rated
- Mechanical dimensions vary with model, typical length 1.38 to 2.63 inches
- Mounting: 1.1 and 2.4 VA models require no hardware; larger models have four-hole mounting
- UL recognition, industry-standard pin spacing
- Low primary to secondary coupling, split bobbin design ensure efficiency
Buy the Hammond 164E36 – Reliable Power Transformer for Industrial Applications
Purchase Hammond 164E36 online—designed for industrial power management with reliable performance, high insulation, and a low profile split bobbin design. Ideal for demanding environments, it offers excellent durability, UL recognition, and versatile voltages ranging from 5V to 36V RMS. Featuring industry-standard pin spacing for easy PCB mounting, these transformers ensure efficient power conversion and safe operation. Whether for automation or industrial systems, buy Hammond 164E36 online today and ensure your power needs are met with high-quality, dependable components that stand the test of time.
Get Hammond 164E36 today—built for precision, high insulation, and long-lasting durability in demanding environments.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 164E36?
You can click on the BUY or RFQ button to purchase 164E36 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 164E36?
You can download the 164E36 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 164E36?
Hammond Manufacturing
