Hammond Manufacturing 186E16 Power Isolation Transformer
The 186E16 is a 53VA low-voltage isolation transformer designed for power management and industrial applications. It features a twin primary of 115/230VAC, operates at 50/60Hz, and provides a 16VAC RMS secondary with a current capacity of 3.5A, center-tapped. The transformer has combination solder or quick-connect terminals, split bobbin construction that eliminates the need for an electrostatic shield, and is Hi-pot tested to 2000Vrms. It is an economical open-style, chassis mount design with a channel frame and thermal class-B insulation, designed to operate at Class-A temperature rise.
Hammond Manufacturing 186E16 Power Isolation Transformer Specifications:
- Primary Voltage: 115/230 VAC Dual Primary
- Secondary Voltage: 16VAC RMS (center-tapped)
- VA Rating: 53 VA
- Current Capacity: 3.5 Amps
- Frequency: 50/60 Hz
- Construction: Split bobbin, open style, chassis mount
- Terminals: Combination solder or quick-connect
- Insulation: Class B, 130°C maximum, thermal class A temperature rise
- Hi-pot Test: 2000 Vrms
- Dimensions: Not specified, designed for panel mounting
- Protection: Standard safety and certification compliance
Buy the Hammond 186E16 – Reliable Power Management Transformer for Industrial Applications
Order the Hammond 186E16 power isolation transformer online now to ensure reliable power management for your industrial and automation needs. This robust, high-capacity transformer features dual primary voltages of 115/230VAC, operates at 50/60Hz, and offers a 16VAC secondary with a current of 3.5A. Its split bobbin construction eliminates the need for a shield, and the combination solder or quick-connect terminals simplify installation. Hi-pot tested to 2000Vrms, it is designed to operate at Class A temperature rise with safety certifications for industrial environments. Purchase now for durable, economical power solutions.
Get Hammond 186E16 today—built for precision and long-lasting durability in power supply solutions.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186E16?
You can click on the BUY or RFQ button to purchase 186E16 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186E16?
You can download the 186E16 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186E16?
Hammond Manufacturing
