Hammond Manufacturing 187F24 Datasheet & Stock
The 187F24 is a 96VA low-voltage isolation transformer featuring a 24VAC center-tapped secondary capable of delivering 4A (RMS). It has a single 115VAC primary and operates at 50/60Hz. The transformer includes combination solder or quick connect terminals and utilizes split bobbin construction, which eliminates the need for an electrostatic shield. It is Hi-pot tested to 2000Vrms, designed with an economical open-style channel frame chassis mount. The product features 130°C Class B insulation and is designed to support a Class A temperature rise. Suitable for power management and industrial applications.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 187F24?
You can click on the BUY or RFQ button to purchase 187F24 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 187F24?
You can download the 187F24 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 187F24?
Hammond Manufacturing
