Hammond Manufacturing 289MG1000 Medical Line Isolation Transformer
The 289MG1000 is a medical-grade plug-in line isolation transformer rated at 1000VA, designed for non-patient connected indoor applications. It provides complete line isolation and noise filtering using a Faraday shield, reducing leakage currents below UL 60601-1 standards. Suitable for sensitive electronic equipment, it features a vented steel housing, hospital-grade grounded input plug, duplex output receptacles, and built-in protection with circuit breaker and thermal cut-out. This transformer ensures reliable power with high efficiency and safety compliance for medical environments.
Hammond Manufacturing 289MG1000 Medical Line Isolation Transformer Specifications:
- VA Capacity: 1000VA
- Input Voltage: 240 VAC
- Input Current: 4.33A
- Output Voltage: 120 VAC
- Output Current: 8.33A
- Leakage Current: <100µA
- Efficiency: 95% (min)
- Housing: Vented 14-gauge steel with white powder paint
- Input Plug: Hospital-grade 6-15P
- Output Receptacles: Duplex 5-15R
- Protection: On-off switch, circuit breaker, thermal cut-out
- Cord Length: 6 ft.
- Dimensions: Standard vented steel housing suitable for indoor use
Buy the Buy Hammond Medical Grade Plug-In Line Isolation Transformer Part Number 289MG1000 Online
Order the Hammond 289MG1000 medical-grade line isolation transformer online today and benefit from enhanced noise filtering, safety features, and dependable power for sensitive electronic devices. Its robust steel housing, hospital-grade plug, and duplex output receptacles ensure safe and reliable operation in clinical environments. Perfect for non-patient connected indoor applications, this transformer provides excellent line isolation and leakage current reduction, meeting UL 60601-1 standards. Secure your sensitive equipment today with this high-quality, efficient transformer designed for medical use.
Buy Hammond 289MG1000 now and experience unmatched reliability and performance for sensitive medical equipment.
