Hammond Manufacturing 298MG1000 Medical Line Isolation Transformer
The 298MG1000 is a medical-grade plug-in line isolation transformer designed for non-patient connected indoor applications. It provides complete line isolation and noise filtering, utilizing a Faraday shield to reduce leakage currents below UL60601-1 standards. Rated at 1000VA with a 120V input and 240V output, it features hospital-grade grounded plugs, duplex output receptacles, and built-in protection including an automatic thermal cutout. Ideal for protecting sensitive electronic equipment in medical and industrial environments, ensuring compliance and reliable performance.
Hammond Manufacturing 298MG1000 Medical Line Isolation Transformer Specifications:
- Power Rating: 1000VA
- Input Voltage: 120 V
- Output Voltage: 240 V
- Current at Input: 8.67 A
- Current at Output: 4.17 A
- Leakage Current: < 100 microamps
- Frequency: 50/60 Hz
- Housing: Ventilated 14 gauge steel, white powder paint
- Input Plug: Hospital Grade 3-wire grounded
- Output Receptacles: Duplex hospital grade
- Protection: On-off switch, circuit breaker, automatic thermal cutout
- Cord Style: 14/3 SJTW, 6 ft.
- Efficiency: Minimum 95%
- Certifications: cULus Listed to UL 60601-1, CSA Certified
Buy the Hammond 298MG1000 – Reliable Medical Grade Line Isolation Transformer for Industrial Applications
Secure your sensitive electronic devices with the Hammond 298MG1000. This 1000VA medical-grade transformer offers complete line isolation, noise filtering, and reliable performance for industrial and healthcare environments. It features hospital-grade grounded plugs, duplex output receptacles, and built-in protection including an automatic thermal cutout. Easy to install with a 6-foot cord, it ensures safety, compliance, and optimal operation of your critical equipment. Order online today and safeguard your electronic systems effectively.
Buy Hammond 298MG1000 now and experience unmatched reliability and performance in medical and sensitive electronic equipment protection.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 298MG1000?
You can click on the BUY or RFQ button to purchase 298MG1000 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 298MG1000?
You can download the 298MG1000 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 298MG1000?
Hammond Manufacturing
