Hammond Manufacturing 560E Audio Transformer
This audio transformer is designed for microphone and line-level applications, offering excellent frequency response from 30 Hz to 15 KHz or 30 Hz to 30 KHz depending on model. It features a rugged epoxy potted case with 9-pin connections, electrostatic shielding, and split windings for circuit flexibility. Primaries and secondaries can be reversed for impedance matching. Overall dimensions measure 1.64 inches by 1.33 inches by 0.85 inches, and it provides reliable, high-quality audio signal transfer with low insertion loss, suitable for professional sound systems.
Hammond Manufacturing 560E Audio Transformer Specifications:
- Application: Microphone to line, isolating or hybrid, matching, bridging
- Impedance: 150/600 Ohms primary, 10K/40K secondary, 5K/20K, 1200/4800 Ohms, 150/600 Ohms, 50/200 Ohms
- Dimensions: 1.64" x 1.33" x 0.85" (41.7mm x 33.8mm x 21.6mm)
- Case: Rugged epoxy potted with 9-pin connections (.025" square, 0.5" long)
- Frequency Response: 30 Hz to 15 KHz or 30 Hz to 30 KHz, typical +/- 0.5 dB
- Insertion Loss: Maximum 1 dB
- Shielding: Electrostatic shield connected to core and pin 'SH'
- Construction: Humbucking, balanced split windings, reversible impedance for versatility
- Shipping Weight: 4 ounces (0.1 kg)
Buy the Buy Hammond Audio Transformer Part Number 560E Online
Enhance your audio setup with the Hammond 560E transformer, designed for microphone and line-level applications. Its epoxy potted case ensures durability, while split windings provide circuit versatility. With excellent frequency response from 30 Hz to 15 KHz or 30 Hz to 30 KHz, it delivers high fidelity sound for professional sound systems. The electrostatic shield minimizes interference, and its compact dimensions make it easy to integrate. Trust Hammond for quality audio components that boost your audio equipment’s performance. Order now for reliable sound quality.
Buy Hammond 560E audio transformer now and experience unmatched performance and reliable sound transfer for professional audio systems.
