Hammond Manufacturing 560L Audio Transformer
This audio transformer provides reliable performance for audio electronic circuits, supporting various impedance configurations and offering excellent frequency response from 30 Hz to 30 kHz. Encased in a rugged black epoxy potting with 9-pin connections, it features electrostatic shielding for noise reduction, balanced split windings for circuit versatility, and primary and secondary reversal capability for impedance matching. The compact dimensions of 1.64 x 1.33 x 0.85 inches make it ideal for professional audio applications, ensuring durability and high-quality signal transfer.
Hammond Manufacturing 560L Audio Transformer Specifications:
- Application: Audio electronic circuits
- Impedance: Primary 12/48 ohms, Secondary 150/600 ohms, or other configurations as listed
- Frequency Response: 30 Hz to 30 kHz typical, 30 Hz to 15 kHz for 560Q
- Insertion Loss: 1 dB maximum
- Case Material: Black epoxy potting
- Connections: 9-pin
- Dimensions: 1.64" x 1.33" x 0.85" (41.7 mm x 33.8 mm x 21.6 mm)
- Weight: 4 oz (0.1 kg)
- Shielding: Electrostatic shield between primary & secondary
- Construction: Bucking, balanced split windings, reversible primary & secondary for impedance matching
Buy the Hammond 560L – Reliable Audio Transformer for Industrial Applications
Enhance your audio system with the Hammond 560L audio transformer, designed for professional applications requiring high reliability and versatility. This transformer provides excellent impedance matching options, robust construction, and a wide frequency response from 30 Hz to 30 kHz, ensuring clean audio signal transfer. Its compact size and epoxy potting make it suitable for various industrial and broadcast environments. Purchase online now to experience dependable performance, superior noise reduction, and durable design that meets the demands of professional audio engineering.
Order your Hammond Series560L audio transformer today and give your audio projects the dependable quality they deserve with superior impedance matching and rugged construction.
