Hammond Manufacturing PCJ1082L Polycarbonate Junction Box
The Hammond PCJ1082L is a robust Type 4X polycarbonate junction box featuring a solid and clear cover, designed for outdoor and indoor electrical control applications. Made from impact-resistant, UV-stabilized polycarbonate, it offers excellent weather resistance, corrosion protection, and high impact tolerance of 16 J (12 ft/lb). The box includes threaded brass inserts, stainless steel fasteners, and a captive gasket for a reliable seal. It’s suitable for chemical plants, wastewater, irrigation, and renewable energy projects, conforming to UL 508A and IEC 60529 standards. Optional inner panels and mounting accessories enhance its versatility.
Hammond Manufacturing PCJ1082L Polycarbonate Junction Box Specifications:
- Material: Injection moulded polycarbonate thermoplastic
- Finish: Light gray
- Flammability: UL 94V-0
- UV Rating: f1 per UL746C, UV stabilized for outdoor use
- Operating Temperature: -35°C to 130°C (-31°F to 266°F)
- Impact Resistance: 16 J (12 ft/lb)
- Standards: UL508A Type 1, 2, 3, 4, 4X, 12, 13; IEC 60529 IP66
- Fasteners: Stainless steel 316 screws, threaded brass inserts
- Seal: Oil resistant gasket for positive seal
- Mounting: Flange or foot mount brackets, multi-directional options
- Certifications: UL, CSA compliant
- Application: Electrical enclosures for industrial, chemical, renewable energy projects
Buy the Buy Hammond PCJ Series Junction Box Part Number PCJ1082L Online
Secure your electrical control projects with the Hammond Series PCJ Impact-Resistant Polycarbonate Junction Box. Designed for outdoor and indoor use, it offers superior weather resistance, UV stabilization, and high-impact strength of 16 J, ensuring long-lasting performance. Featuring stainless steel fasteners, threaded brass inserts, and a captive gasket, this enclosure guarantees a reliable seal. It’s ideal for chemical plants, wastewater management, irrigation, and renewable energy applications. Easy to mount with optional accessories available for enhanced versatility and protection levels.
Order your Hammond SeriesPCJ1082L impact-resistant junction box today and ensure your electrical control systems are protected with durable, weatherproof enclosure.
Frequently Asked Questions
Where can I buy Hammond Manufacturing PCJ1082L?
You can click on the BUY or RFQ button to purchase PCJ1082L from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part PCJ1082L?
You can download the PCJ1082L datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of PCJ1082L?
Hammond Manufacturing
