Honeywell SZXSLF14 Power Relay
The Honeywell SZX-SLF-14 is a compact, high-reliability power relay designed for control panels, automation systems, and industrial machinery. It features a small package design, SILVER CADIUM OXIDE contacts, high dielectric strength of 1,800 Vac, and durability with mechanical and electrical longevity. Available with options like LED indicators, surge protection diodes, and both plug-in and PCB mounting. This versatile relay supports resistive loads up to 10A, operates quickly within 25ms, and withstands vibration and shock for demanding industrial environments, ensuring stable system control.
Honeywell SZXSLF14 Power Relay Specifications:
- Contact Material: Silver Cadium Oxide
- Contact Resistance: Max. 50 MOhm
- Operate Time: Max. 25 ms
- Release Time: Max. 25 ms
- Mechanical Operating Frequency: 18,000 operations/hour
- Electrical Operating Frequency: 1,800 operations/hour
- Insulation Resistance: Min. 100 MΩ at 500 Vdc
- Dielectric Withstand Voltage: 1,800 Vac 50/60 Hz for one minute between non-current carrying parts, 1,000 Vac between contacts of same polarity
- Vibration Resistance: Mechanical durability 10-55 Hz at double amplitude of 1.0 mm, Malfunction durability same
- Shock Resistance: Mechanical durability 1,000 m/s², Malfunction 200 m/s²
- Service Life: Mechanical - Min. 50 million operations AC, Min. 100 million DC; Electrical DPDT - Min. 500,000 operations; 4PDT - Min. 200,000 operations
- Physical Dimensions vary by model; typical mounting and terminal configurations are detailed in datasheets
- Maximum switching capacity: 1100 VA resistive load, 825 VA inductive load, support for loads up to 10A
Buy the Honeywell SZR-LY Series – Reliable Power Relay for Industrial Applications
Purchase the Honeywell SZR-LY power relay today for your control panel, automation, or industrial machinery. Engineered for high reliability, quick response within 25ms, and withstands vibration and shock, ensuring stable operation. It offers options like LED indicators, surge protection diodes, and various mounting configurations. With a maximum load capacity of 10A, high dielectric strength of 1,800 Vac, and a proven service life, this relay guarantees long-lasting performance in demanding environments. Order now for fast, secure online delivery and seamless integration into your system.
Get Honeywell SZR-LY Series power relay today—designed for durability and quick response in industrial control panels and automation systems.
Frequently Asked Questions
Where can I buy Honeywell SZXSLF14?
You can click on the BUY or RFQ button to purchase SZXSLF14 from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part SZXSLF14?
You can download the SZXSLF14 datasheet or visit the Honeywell website for support.
Who is the manufacturer of SZXSLF14?
Honeywell
