IDEC Corporation LBW7MP1T04S Pushbutton Switch
The LBW7MP1T04S is a high-quality illuminated pushbutton switch featuring a square plastic bezel with a white lens, suitable for panel mounting in industrial control systems. It offers momentary operation, IP65 protection, and LED illumination rated for 5V DC with a lifespan of approximately 30,000 hours. Ideal for applications requiring clear visibility and durable operation, this switch supports solder/tab or PC board terminals and provides reliable switching with a variety of color options. Perfect for automation, machinery control, and safety systems.
IDEC Corporation LBW7MP1T04S Pushbutton Switch Specifications:
- Bezel Material: Plastic (white)
- Operation Type: Momentary
- Protection Degree: IP65 from the front
- Rated Operating Voltage: 5V DC
- LED Lifespan: Approx. 30,000 hours
- Contact Material: Gold-plated
- Contact Configuration: SPDT (Single Pole Double Throw)
- Terminal Style: Solder/tab or PC board terminals
- Weight: Approximately 17g
- Operating Temperature: -25°C to +55°C (no freezing)
- Mounting Panel Thickness: 0.5 to 3.2mm
- Dimensions: 25mm (standard bezel), 29.9mm (flush bezel)
- Color Options: Amber, Green, Red, Blue, White, Yellow
- Soldering Temperature: 350°C within 3 seconds
- Ingress Protection: IP65 from the front
- Environmental Resistance: Vibration resistance at 55Hz, amplitude 0.5mm
Buy the IDE Series LBW7MP1T04S: Illuminated Pushbutton Switch with White Lens
Order the IDE Series LBW7MP1T04S illuminated pushbutton switch online today to enhance your control panel with durable IP65 protection, reliable 5V DC LED illumination, and easy mounting options. Its robust design ensures long-lasting operation in industrial environments, making it ideal for automation, machinery, and safety control. With multiple color options and a lifespan of approximately 30,000 hours, this switch guarantees clear visibility and dependable performance for your automation needs. Buy now for quick delivery and excellent quality.
Get IDE Series LBW7MP1T04S today—built for rugged industrial environments with IP65 protection and long-lasting LED illumination.
Frequently Asked Questions
Where can I buy IDEC Corporation LBW7MP1T04S?
You can click on the BUY or RFQ button to purchase LBW7MP1T04S from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part LBW7MP1T04S?
You can download the LBW7MP1T04S datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of LBW7MP1T04S?
IDEC Corporation
