IDEC Corporation LW1AL3G Oiltight Switch
The LW1AL3G is a 22mm oiltight switch and pilot device designed for industrial applications featuring an illuminated mushroom operator with a yellow LED indicator and robust construction for long-lasting durability and reliable performance in demanding environments.
IDEC Corporation LW1AL3G Oiltight Switch Specifications:
- Diameter: 22mm
- Operation type: Momentary
- Operator style: Mushroom
- Color: Yellow LED indicator
- Ingress Protection: IP66
- Material: Metal and durable plastic
- Operating voltage: 6V DC/AC, 12V DC/AC, 24V DC/AC, 120V AC
- Contact configuration: Normally Open (NO)
- Mounting orientation: Panel mount
- Temperature Range: -25°C to +55°C
- Terminals: Solder/Tab or Screw terminal options
- Suitable for panel thickness: 0.8 to 6 mm
- Rated capacity: 5A at 250V AC
- Conformance: UL and CSA certified
- Environmental resistance: Oiltight, dust-tight
Buy the Idec Series LW: 22mm Oiltight Switches and Pilot Devices: LW1AL3G
Purchase the Idec LW1AL3G oiltight switch online today and ensure your industrial automation systems are equipped with reliable, durable, and easy-to-install controls. Designed for demanding environments, this 22mm mushroom operator features a bright yellow LED indicator for clear visibility and a robust construction to withstand dust, moisture, and oil exposure. Whether you need a momentary switch or a maintained contact, this switch provides superior performance, easy mounting, and conformance to safety standards for optimal operation.
Get Idec LW1AL3G today—built for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy IDEC Corporation LW1AL3G?
You can click on the BUY or RFQ button to purchase LW1AL3G from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part LW1AL3G?
You can download the LW1AL3G datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of LW1AL3G?
IDEC Corporation
