INFINEON FS50R12W1T7B11BOMA1 Power Module
The FSS50R12W1T7 module is a high-performance power inverter component designed for various electrical applications such as auxiliary inverters, air conditioning systems, motor drives, servo drives, and UPS systems. It features advanced TRENCHSTOP IGBT7 technology with emitter-controlled diodes, achieving low Veesat and overload operation up to 175°C. Its compact design uses PressFIT contact technology and Al₂O₃ substrate with low thermal resistance, ensuring high power density and reliable insulation for demanding industrial environments.
INFINEON FS50R12W1T7B11BOMA1 Power Module Specifications:
- Collector-Emitter Voltage: 1200 V
- DC Forward Current: 50 A
- Peak Forward Current: 100 A (te=1ms)
- Gate-Emitter Peak Voltage: +20 V
- Collector-Emitter Saturation Voltage: 1.64 V at 50A
- Gate Threshold Voltage: 5.15 V to 6.45 V
- Gate Charge: 0.92 µC
- Thermal Resistance, Junction to Heatsink: 1.05 KW
- Insulation Test Voltage RMS: 25 kV
- Creepage Distance: 115 mm
- Weight: 24.9 g
- Storage Temperature: -40°C to 125°C
- Operating Temperature: -40°C to 175°C
- Peak Reverse Voltage of Diode: 1200 V
- ESD and dielectric insulation properties compliant with IEC standards
- Dimensions and material specifications for module packaging and contacts are aligned with industry standards.
Buy the Infineon Series EasyPACK Inverter: FS50R12W1T7
Purchase the Infineon FS50R12W1T7 power module online today for reliable, high-efficiency performance in industrial inverter systems. Designed with advanced IGBT7 technology and emitter-controlled diodes, this compact module delivers high power density and excellent thermal management. Its PressFIT contact technology and robust insulation ensure durable operation under demanding conditions, making it ideal for motor drives, air conditioning units, and UPS systems. Buy now to ensure your projects benefit from industry-leading quality and long-term reliability.
Get Infineon FS50R12W1T7 today—built for precision and long-lasting durability in high-power inverter applications.
Frequently Asked Questions
Where can I buy INFINEON FS50R12W1T7B11BOMA1?
You can click on the BUY or RFQ button to purchase FS50R12W1T7B11BOMA1 from an authorized INFINEON distributor.
How do I troubleshoot issues or seek technical support for part FS50R12W1T7B11BOMA1?
You can download the FS50R12W1T7B11BOMA1 datasheet or visit the INFINEON website for support.
Who is the manufacturer of FS50R12W1T7B11BOMA1?
INFINEON
