ITT CANNON DAMM15SD D-Sub Connector
The Cannon D*M high-reliability D-Sub connector featuring 15 contacts supports wire gauges from AWG 20-28, with a maximum current of 7.5 A. Designed for rugged applications, it withstands 1000 VAC dielectric withstand voltage and operates within -55°C to +150°C temperature range. The connector's steel shell is finished with yellow chromate over zinc, ensuring corrosion resistance. Contact material is copper alloy with gold over nickel finish for reliable electrical performance. Suitable for PCB socket mounting with right-angled contact, it withstands 500 mating cycles and has a salt spray resistance of 48 hours, making it ideal for industrial environments.
ITT CANNON DAMM15SD D-Sub Connector Specifications:
- Contact arrangement: 15 contacts, size 20
- Wire Gauge Range: AWG 20-28
- Maximum Current: 7.5 A
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Operating Temperature: -55°C to +150°C
- Shell Material: Steel with yellow chromate over zinc finish
- Insulator Material: Thermoplastic, UL 94V-0
- Mating Cycles: 500
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Hardware: 120 inch (3.05mm) through hole
Buy the Buy Cannon D-Sub Part Number DAMM15SD Online
Purchase the Cannon D-Sub high-reliability connector with 15 contacts for industrial and electronic projects. Featuring a steel shell with corrosion-resistant yellow chromate finish, copper alloy contacts with gold over nickel, and support for wire gauges from AWG 20-28, it offers excellent durability. Capable of withstanding up to 500 mating cycles and 1000 VAC dielectric voltage, this connector performs reliably from -55°C to +150°C. Perfect for PCB mounting and harsh environments, order now for quick online delivery and secure connections.
Order your Cannon Series DAMM15SD high-reliability D-Sub connector today and ensure robust performance in demanding industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON DAMM15SD?
You can click on the BUY or RFQ button to purchase DAMM15SD from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DAMM15SD?
You can download the DAMM15SD datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DAMM15SD?
ITT CANNON
