ITT CANNON DAMN15PNK87 High Reliability D-Sub Connector
The Cannon DAMN-15P-N-K87 is a high-reliability D-Sub connector designed for industrial and electronic applications. It features 15 contact positions suitable for wire gauges between AWG 20 and 28, with a maximum current rating of 7.5 A and a contact resistance of 7.5 milliohm. The connector withstands dielectric voltages up to 1000 VAC at sea level and operates over a temperature range of -55°C to +125°C. Its steel shell, nickel and tin finish, and gold-flashed contacts ensure durability and corrosion resistance for demanding environments.
ITT CANNON DAMN15PNK87 High Reliability D-Sub Connector Specifications:
- Contacts: 15 pin configuration, size 20
- Wire Gauge Range: AWG 20-28
- Maximum Current: 7.5 A
- Contact Resistance: 7.5 milli Ohm max
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel with pure tin over nickel finish
- Insulator Material: Thermoplastic, UL 94V-0 rated
- Insulator Color: Black
- Contact Material: Copper alloy with gold flash over nickel finish
- Mating Cycles: 200
- Hardware: 0.300-inch standoff, 4-40 screw lock, board lock
- Salt Spray Test: 20 hours
Buy the Cannon DAMN-15P-N-K87 – Reliable D-Sub Connector for Industrial Applications
Purchase the Cannon DAMN-15P-N-K87 online for your electronic and industrial wiring needs. Designed with 15 contacts, this high-reliability connector features gold-flash contacts, a steel shell with nickel and tin finishes, and UL-rated thermoplastic insulators. Its robust construction ensures durability in harsh environments, with a maximum current of 7.5 A and excellent dielectric resistance up to 1000 VAC. Ideal for applications requiring secure, long-lasting connections, it offers 200 mating cycles for extensive use in industrial and electronic systems.
Get Cannon DAMN-15P-N-K87 today—built for precision, durability, and high-reliability connection in demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON DAMN15PNK87?
You can click on the BUY or RFQ button to purchase DAMN15PNK87 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DAMN15PNK87?
You can download the DAMN15PNK87 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DAMN15PNK87?
ITT CANNON
