ITT CANNON DCMAM37SF225 D-Sub connector
The DCMAM37SF225 is a high-reliability D-Sub connector designed for secure electrical connections in various industrial and electronic applications. It features 37 contacts with a crimp termination, a compact high-density design, and robust stainless steel shell construction with passivation for durability. Capable of withstanding voltages up to 1000 VAC and operating temperatures from -55°C to +150°C, it supports 500 mating cycles. Its gold-over-nickel contact finish ensures excellent conductivity and corrosion resistance, making it ideal for demanding environments requiring reliable, long-lasting connections.
ITT CANNON DCMAM37SF225 D-Sub connector Specifications:
- Contact Arrangement: 37 contacts, size 20
- Wire Gauge Range: AWG 20-28, High Density: AWG 22-28
- Mating Cycles: 500
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 7.5 A max
- Contact Resistance: 10 milli Ohm max
- Operating Temperature: -55°C to +150°C
- Shell Material: Passivated stainless steel
- Shell Finish: Stainless steel
- Insulator Material: Thermoplastic, UL 94V-0
- Insulator Color: Black
- Gender: Socket
- Contact Type: Crimp
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel (Performance Class 2)
- Hardware: 120-inch (3.05mm) Through Hole
Buy the Cannon Series D*MA D-Sub Connector: DCMAM37SF225
Experience secure, durable, and high-performance connections with the Cannon D-Sub connector. Designed for demanding industrial environments, it features 37 contacts, stainless steel shell, gold-over-nickel finish, and supports up to 500 mating cycles. Operating from -55°C to +150°C and rated for 1000 VAC, this connector ensures reliable electrical performance. Its compact high-density design and robust construction make it ideal for applications requiring long-lasting and corrosion-resistant connections. Purchase online today for dependable connectivity in your projects.
Buy Cannon DCMAM37SF225 now and experience unmatched reliability and performance in your electronic and industrial connections.
